2EYP
ActiveTE Connectivity Raychem Cable Protection
POWER LINE FILTER 50HZ/60HZ 2A 250VAC QUICK CONNECT FLANGE MOUNT
Deep-Dive with AI
Search across all available documentation for this part.
2EYP
ActiveTE Connectivity Raychem Cable Protection
POWER LINE FILTER 50HZ/60HZ 2A 250VAC QUICK CONNECT FLANGE MOUNT
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 2EYP |
|---|---|
| Applications | General Purpose |
| Approval Agency | VDE, CSA, UR |
| Configuration | Single Stage |
| Current | 2 A |
| Filter Type | Single Phase |
| Frequency - Operating [Max] | 60 Hz |
| Frequency - Operating [Min] | 50 Hz |
| Inductance | 5.7 mH |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 40 °C |
| Operating Temperature [Min] | -10 °C |
| Termination Style | PC Pins |
| Voltage - Rated AC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 192 | $ 20.50 | |
Description
General part information
2E Series
Single Phase EMC/EMI Line Filter 2 A 250V 50/60Hz Single Stage PC Pins
