242125-10-EE
ActiveAmphenol RF
N-TYPE TO SMA JACK ADAPTER 50 OH
Deep-Dive with AI
Search across all available documentation for this part.
242125-10-EE
ActiveAmphenol RF
N-TYPE TO SMA JACK ADAPTER 50 OH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 242125-10-EE |
|---|---|
| Adapter Type | Jack to Jack |
| Body Finish | Nickel |
| Body Material | Brass |
| Center Contact Material | Beryllium Copper |
| Center Contact Plating | Gold |
| Center Gender | Female to Female |
| Conversion Type | Between Series |
| Convert From (Adapter End) | Female Socket, SMA Jack |
| Convert To (Adapter End) | Female Socket, N Jack |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Impedance | 50 Ohms |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Mating Cycles | 500 |
| Mounting Feature | Bulkhead |
| Operating Temperature [Max] | 165 °C |
| Operating Temperature [Min] | -65 ░C |
| Style | Straight |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 58.26 | |
| 10 | $ 45.14 | |||
| 25 | $ 40.98 | |||
| 50 | $ 38.18 | |||
| 100 | $ 35.64 | |||
| 250 | $ 32.65 | |||
Description
General part information
242125 Series
Adapter Coaxial Connector SMA Jack, Female Socket To N Jack, Female Socket 50 Ohms
Documents
Technical documentation and resources
No documents available
