DCZ4SD3077BK

Active

Hammond Manufacturing

DOOR STEEL 76.8X22.4X0.75" BLACK

Search across all available documentation for this part.

Active

Hammond Manufacturing

DOOR STEEL 76.8X22.4X0.75" BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	DCZ4SD3077BK

Color	Black
Features	Handles
For Use With/Related Products	DCZ4 Series
Material	Metal, Steel
Size / Dimension [x]	1951 mm
Size / Dimension [x]	76.811 in
Size / Dimension [y]	22.402 in
Size / Dimension [y]	569 mm
Size / Dimension [z]	19 mm
Size / Dimension [z]	0.748 "
Type	Front, Door, Rear
Ventilation	Non-Vented

Part	Ventilation	Color	Material	Type	For Use With/Related Products	Features	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension
Hammond Manufacturing DCZ4SD3077BK	Non-Vented	Black	Metal Steel	Door Front Rear	DCZ4 Series	Handles	22.402 in	19 mm	1951 mm	569 mm	76.811 in	0.748 "
Hammond Manufacturing DCZ4SP7742BK	Non-Vented	Black	Metal Steel	Panel Side	DCZ4 Series		34.488 in				76.929 in	0.787 in	20 mm 876 mm 1954 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Metal, Steel Door, Front or Rear 76.811" L x 22.402" W x 0.748" H (1951.00mm x 569.00mm x 19.00mm) Black

Technical documentation and resources

No documents available
