Q-2K039000M0.5M

Active

Amphenol Custom Cable

CBL ASSY SMA-NTYPE PLG-PL 19.69"

Deep-Dive with AI

Search across all available documentation for this part.

Q-2K039000M0.5M

Active

Amphenol Custom Cable

CBL ASSY SMA-NTYPE PLG-PL 19.69"

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-2K039000M0.5M

1st Connector	SMA Plug, Right Angle
1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	N-Type Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Type	LMR 240
Color	Black
Features	Shielded
Frequency - Max [Max]	6000 MHz
Length	50 cm
Length	19.69 "
Overall Impedance	50 Ohms
Style	SMA to N-Type

Q-2K0390 Series

Part	Length	Length	Length	1st Contact Gender	Style	1st Connector	Color	Cable Type	2nd Connector Mounting Type	1st Connector Mounting Type	2nd Connector	Frequency - Max [Max]	2nd Contact Gender	Overall Impedance	Features	Length [x]	Length [x]
Amphenol Custom Cable Q-2K039000M072i	6 ft	72 in	1.8 m	Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded
Amphenol Custom Cable Q-2K039000M003M	9.8 '	118.1 in	3 m	Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded
Amphenol Custom Cable Q-2K039000M1.5M	4.9 ft	59.1 in	1.5 m	Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded
Amphenol Custom Cable Q-2K039000M0.5M		19.69 "	50 cm	Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded
Amphenol Custom Cable Q-2K039000M2.5M	8.2 '	98.4 in	2.5 m	Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded
Amphenol Custom Cable Q-2K039000M060i	5 ft	5 '	1.5 m	Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded
Amphenol Custom Cable Q-2K039000M001M	3.3 ft	39.4 in	1 m	Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded
Amphenol Custom Cable Q-2K039000M024i		24 "	609.6 mm	Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded
Amphenol Custom Cable Q-2K039000M036i		36 in	91.44 cm	Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded
Amphenol Custom Cable Q-2K039000M018i				Male	SMA to N-Type	Right Angle SMA Plug	Black	LMR 240	Free Hanging (In-Line)	Free Hanging (In-Line)	N-Type Plug	6000 MHz	Male	50 Ohms	Shielded	457.2 mm	457.2 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 114.77
		25	$ 112.57
		50	$ 110.37
		100	$ 108.18
		250	$ 105.98

Description

General part information

Q-2K0390 Series

Cable Assembly Coaxial SMA to N-Type LMR 240 19.69" (500.00mm)

Documents

Technical documentation and resources

No documents available
