8AP-03PMMP-SF7001

Active

Amphenol LTW

M SERIES, GUIDED M8, 3A, 03 PINS, RECEPTACLE, HEXAGONAL ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Amphenol LTW

M SERIES, GUIDED M8, 3A, 03 PINS, RECEPTACLE, HEXAGONAL ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	8AP-03PMMP-SF7001

Color	Black
Connector Type	Receptacle, Male Pins
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	3 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Mounting Type	Through Hole, Panel Mount
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	M8-3
Shielding	Unshielded
Termination	Solder
Voltage Rating	50 VAC, 60 VDC

Part	Shell Material	Shielding	Contact Finish - Mating	Voltage Rating	Orientation	Mounting Feature	Shell Size - Insert	Current Rating (Amps)	Color	Connector Type	Primary Material	Operating Temperature [Min]	Operating Temperature [Max]	Insert Material	Mounting Type	Ingress Protection	Termination	Contact Material
Amphenol LTW 8AP-03PMMP-SF7001	Glass Filled Nylon Polyamide (PA)	Unshielded	Gold	50 VAC 60 VDC	Keyed	Bulkhead - Front Side Nut	M8-3	3 A	Black	Male Pins Receptacle	Plastic	-40 °C	105 ░C	Polyamide (PA) Nylon Glass Filled	Panel Mount Through Hole	IP67 - Dust Tight Waterproof	Solder	Copper Alloy

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Circular Connector Receptacle, Male Pins Solder
