9589-1"X36YD

Active

3M (TC)

TAPE DBL SIDED WHITE 1"X36YDS

Search across all available documentation for this part.

Active

3M (TC)

TAPE DBL SIDED WHITE 1"X36YDS

Technical Specifications

Parameters and characteristics for this part

Specification	9589-1"X36YD

Adhesive	Acrylic, 700
Color	White
Length	36 yd
Length	32.9 m
Length	108 ft
Shelf Life	18 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	70 °F
Storage/Refrigeration Temperature	21 °C
Tape Type	Double Coated, Double Sided
Temperature Range [Max]	38 °C
Temperature Range [Max]	100 °F
Temperature Range [Min]	21 °C
Temperature Range [Min]	70 °F
Thickness	9 mils
Thickness	0.009 in
Thickness	0.229 mm
Thickness - Adhesive	0.003 "
Thickness - Adhesive	0.076 mm
Thickness - Adhesive	3 mils
Thickness - Backing, Carrier	0.006 in
Thickness - Backing, Carrier	6 mils
Thickness - Backing, Carrier	0.152 mm
Usage	Holding, Mounting, Joining
Width [x]	25.4 mm
Width [x]	1 in

Part	Color	Temperature Range [Max]	Temperature Range [Min]	Temperature Range [Max]	Temperature Range [Min]	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Tape Type	Width [x]	Width [x]	Usage	Length	Length	Length	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Shelf Life	Adhesive	Thickness	Thickness	Thickness	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature	Shelf Life Start
3M (TC) 9589-1"X36YD	White	38 °C	21 °C	100 °F	70 °F	0.006 in	6 mils	0.152 mm	Double Coated Double Sided	25.4 mm	1 in	Holding Joining Mounting	36 yd	32.9 m	108 ft	0.003 "	0.076 mm	3 mils	18 Months	Acrylic 700	9 mils	0.009 in	0.229 mm	70 °F	21 °C	Date of Manufacture

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Double Coated, Double Sided Tape Acrylic, 700 Adhesive White 1.00" (25.40mm) X 108' (32.9m) 36 yds
