112162RP

Active

Amphenol RF

CONN RPBNC PLUG R/A 50OHM SOLDER

Search across all available documentation for this part.

Active

Amphenol RF

CONN RPBNC PLUG R/A 50OHM SOLDER

Technical Specifications

Parameters and characteristics for this part

Specification	112162RP

Body Finish	Nickel
Body Material	Brass
Cable Group	RG-58, 58C
Center Contact Material	Phosphor Bronze
Center Contact Plating	Gold
Connector Style	RP-BNC
Connector Type	Plug, Female Socket
Contact Termination	Solder
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Bayonet Lock
Frequency - Max [Max]	3 GHz
Housing Color	Silver
Impedance	50 Ohms
Includes	1 Connector, 1 Ferrule, 1 End Cap
Insertion Loss	0.2 dB
Mating Cycles	500
Mounting Type	Free Hanging (In-Line), Right Angle
Number of Ports	1
Operating Temperature [Max]	165 °C
Operating Temperature [Min]	-65 ░C
Shield Termination	Crimp
Voltage Rating	500 V

Part	Center Contact Material	Includes	Housing Color	Contact Termination	Connector Style	Fastening Type	Body Finish	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Body Material	Dielectric Material	Mating Cycles	Insertion Loss	Impedance	Cable Group	Frequency - Max [Max]	Voltage Rating	Number of Ports	Connector Type	Shield Termination	Center Contact Plating
Amphenol RF 112162RP	Phosphor Bronze	1 Connector 1 End Cap 1 Ferrule	Silver	Solder	RP-BNC	Bayonet Lock	Nickel	-65 ░C	165 °C	Free Hanging (In-Line) Right Angle	Brass	Polytetrafluoroethylene (PTFE)	500	0.2 dB	50 Ohms	58C RG-58	3 GHz	500 V	1	Female Socket Plug	Crimp	Gold

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

RP-BNC Connector Plug, Female Socket 50 Ohms Free Hanging (In-Line), Right Angle Solder
