431113-09-0

Active

Curtis Industries

CONN BARRIER STRIP 9CIRC 0.438"

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Terminal Blocks Catalog

431113-09-0

Active

Curtis Industries

CONN BARRIER STRIP 9CIRC 0.438"

Deep-Dive with AI

DocumentsDatasheet Terminal Blocks Catalog

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 7.80
		10	$ 6.15
		25	$ 5.85
		50	$ 5.31
		100	$ 5.10
		250	$ 4.50
		500	$ 4.20
		1000	$ 3.90

Description

General part information

431113 Series

9 Circuit 0.438" (11.12mm) Barrier Block Connector Screws

Documents

Technical documentation and resources

Datasheet

Terminal Blocks Catalog

Datasheet

Specification	431113-09-0	431113 Series

Barrier Type	2 Wall (Dual)	2 Wall (Dual)
Bottom Termination	PC Pin	PC Pin
Current Rating (Amps)	20 A	20 A
Material - Insulation	Polypropylene (PP)	Polypropylene (PP)
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	Through Hole	Through Hole
Number of Circuits	-	4 - 24
Number of Circuits	-	8
Number of Rows	1	1
Number of Wire Entries	9	4 - 19
Number of Wire Entries	-	22
Operating Temperature	105 C	105 C
Pitch [x]	11.12 mm	11.12 mm
Pitch [x]	0.438 in	0.438 in
Terminal Block Type	Barrier Block	Barrier Block
Terminal Screw Material	Steel, Stainless	Steel, Stainless
Top Termination	Screws	Screws
Voltage Rating	600 V	600 V
Wire Gauge [Max]	22 AWG	22 AWG
Wire Gauge [Min]	12 AWG	12 AWG

Part

Operating Temperature

Mounting Type

Voltage Rating

Pitch [x]

Barrier Type

Material - Insulation

Current Rating (Amps)

Number of Circuits

Wire Gauge [Min]

Wire Gauge [Max]

Number of Rows

Number of Wire Entries

Material Flammability Rating

Bottom Termination

Terminal Screw Material

Top Termination

Terminal Block Type

Number of Wire Entries [custom]

Number of Circuits [custom]

Curtis Industries

431113-06-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Curtis Industries

431113-19-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Curtis Industries

431113-09-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Curtis Industries

431113-14-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Curtis Industries

431113-04-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Curtis Industries

431113-22-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Curtis Industries

431113-10-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Curtis Industries

431113-07-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Curtis Industries

431113-05-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Curtis Industries

431113-24-0

105 C

Through Hole

600 V

11.12 mm

0.438 in

2 Wall (Dual)

Polypropylene (PP)

20 A

12 AWG

22 AWG

UL94 V-0

PC Pin

Stainless, Steel

Screws

Barrier Block

Part	Operating Temperature	Mounting Type	Voltage Rating	Pitch [x]	Pitch [x]	Barrier Type	Material - Insulation	Current Rating (Amps)	Number of Circuits	Wire Gauge [Min]	Wire Gauge [Max]	Number of Rows	Number of Wire Entries	Material Flammability Rating	Bottom Termination	Terminal Screw Material	Top Termination	Terminal Block Type	Number of Wire Entries [custom]
Curtis Industries 431113-06-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A	6	12 AWG	22 AWG	1	6	UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block
Curtis Industries 431113-19-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A	19	12 AWG	22 AWG	1	19	UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block
Curtis Industries 431113-09-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A		12 AWG	22 AWG	1	9	UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block
Curtis Industries 431113-14-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A	14	12 AWG	22 AWG	1	14	UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block
Curtis Industries 431113-04-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A	4	12 AWG	22 AWG	1	4	UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block
Curtis Industries 431113-22-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A	22	12 AWG	22 AWG	1		UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block	22
Curtis Industries 431113-10-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A	10	12 AWG	22 AWG	1	10	UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block
Curtis Industries 431113-07-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A	7	12 AWG	22 AWG	1	7	UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block
Curtis Industries 431113-05-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A	5	12 AWG	22 AWG	1	5	UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block
Curtis Industries 431113-24-0	105 C	Through Hole	600 V	11.12 mm	0.438 in	2 Wall (Dual)	Polypropylene (PP)	20 A	24	12 AWG	22 AWG	1		UL94 V-0	PC Pin	Stainless, Steel	Screws	Barrier Block
