BLE DA14531 WLCSP17 DAUGHTERCARD

DA14531-00OGDB-P

Active

Renesas Electronics Corporation

BLE DA14531 WLCSP17 DAUGHTERCARD

Description Specifications Series Pricing CAD Documents

Description

General part information

DA14531 Series

SmartBond™ DA14531 Transceiver; Bluetooth® 5.x 2.4GHz Evaluation Board

Technical Specifications

Parameters and characteristics for this part

Specification	DA14531-00OGDB-P

Contents	Board
For Use With/Related Products	DA14531
Frequency	2.4 GHz
Supplied Contents	Board(s)
Type	Bluetooth® 5.x, Transceiver, Bluetooth® 5.x (BLE)
Utilized IC / Part	DA14531

DA14531 Series

Part	Supplied Contents	For Use With/Related Products	Type	Utilized IC / Part	Contents	Frequency	Interconnect System	Platform	Function	Current - Receiving	Package / Case	Sensitivity	Antenna Type	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Operating Temperature (Min)	Operating Temperature (Max)	Frequency (Max)	Frequency (Min)	Serial Interfaces	Current - Transmitting	Mounting Type	Power - Output	RF Family/Standard	Memory Type	Memory Size (SRAM)	Memory Size (ROM)	Memory Size (Flash)	Protocol	Package Name	Package Width	Package Length	GPIO Count
Renesas Electronics Corporation DA14531-00FXDEVKT-P	Board(s)	DA14531	Bluetooth® 5.x (BLE) Transceiver	DA14531	Board	2.4 GHz
Renesas Electronics Corporation US159-DA14531EVZ			RF	DA14531	Board		Pmod	Pmod™	Bluetooth Low Energy (BLE)
Renesas Electronics Corporation DA14531-00OGDB-P	Board(s)	DA14531	Bluetooth® 5.x Bluetooth® 5.x (BLE) Transceiver	DA14531	Board	2.4 GHz
Renesas Electronics Corporation DA14531MOD-00F01002				DA14531						2 mA	16-SMD Module	-93 dBm	Integrated Trace	3.3 V	1.8 V	-40 °C	85 °C	2.4835 GHz	2.4 GHz	ADC GPIO I2C SPI UART	4 mA	Surface Mount	2.2 dBm	Bluetooth	Flash ROM SRAM	48 kB	144 kB	128 kB	Bluetooth v5.1
Renesas Electronics Corporation DA14531-00000OG2			TxRx + MCU			2.4 GHz				2.2 mA	17-XFBGA WLCSP	-94 dBm		3.3 V	1.1 V	-40 °C	85 °C			ADC GPIO I2C SPI UART	3.5 mA	Surface Mount	2.5 dBm	Bluetooth	RAM ROM		144 kB		Bluetooth v5.1	17-WLCSP	1.694 mm	2.032 mm	6
Renesas Electronics Corporation DA14531MOD-00DEVKT-P	Board(s)	DA14531	Bluetooth® 5.x (BLE) Transceiver	DA14531	Board	2.4 GHz
Renesas Electronics Corporation DA14531-00FXDB-P	Board(s)	DA14531	Bluetooth® 5.x (BLE) Transceiver	DA14531	Board	2.4 GHz
Renesas Electronics Corporation DA14531-00FXDEVKT-U	Board(s)	DA14531	Bluetooth® 5.x (BLE) Transceiver	DA14531	Board	2.4 GHz
