PTP15-48-S12
ActiveCUI Inc.
ISOLATED DC/DC CONVERTERS - THROUGH HOLE DC-DC, ISOLATED, 15 W, 36-75 VDC INPUT, 12 VDC, 1.25 A, SINGLE REGULATED OUTPUT, DIP, MED
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PTP15-48-S12
ActiveCUI Inc.
ISOLATED DC/DC CONVERTERS - THROUGH HOLE DC-DC, ISOLATED, 15 W, 36-75 VDC INPUT, 12 VDC, 1.25 A, SINGLE REGULATED OUTPUT, DIP, MED
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PTP15-48-S12 |
|---|---|
| Applications | Medical |
| Approval Agency | UKCA, CE |
| Current - Output (Max) [Max] | 1.25 A |
| Efficiency | 88 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 105 C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4 Lead |
| Package / Case | 5-DIP Module |
| Power (Watts) | 15 W |
| Size / Dimension [x] | 2 in |
| Size / Dimension [x] | 50.8 mm |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [z] | 12 mm |
| Size / Dimension [z] | 0.47 " |
| Standard Number | 60601-1 |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V |
| Voltage - Input (Min) [Min] | 36 V |
| Voltage - Isolation | 5.6 kV |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
PTP15 Series
Isolated DC/DC Converters - Through Hole dc-dc, isolated, 15 W, 36-75 Vdc input, 12 Vdc, 1.25 A, single regulated output, DIP, MED
