MPS-203R
ActiveTE Connectivity Raychem Cable Protection
SWITCH PUSHBUTTON DPDT 3A 125V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MPS-203R
ActiveTE Connectivity Raychem Cable Protection
SWITCH PUSHBUTTON DPDT 3A 125V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MPS-203R |
|---|---|
| Actuator Marking | No Marking |
| Actuator Type | Plunger for Cap |
| Circuit | DPDT |
| Current Rating (Amps) | 3 A |
| Electrical Life | 25000 Steps |
| Features | Tactile/Audible Feedback |
| Mounting Type | Panel Mount, Rear |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -20 C |
| Switch Function | On-Mom |
| Termination Style | Solder Lug |
| Type | Standard |
| Voltage Rating - AC | 125 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 28.11 | |
| 25 | $ 24.38 | |||
| 100 | $ 22.23 | |||
Description
General part information
MPS-203 Series
Pushbutton Switch DPDT Standard Panel Mount, Rear
