LFE2-70E-7FN900C

Active

LATTICE SEMICONDUCTOR

IC FPGA 583 I/O 900FBGA

Search across all available documentation for this part.

Active

LATTICE SEMICONDUCTOR

IC FPGA 583 I/O 900FBGA

Technical Specifications

Parameters and characteristics for this part

Specification	LFE2-70E-7FN900C

Mounting Type	Surface Mount
Number of I/O	583
Number of LABs/CLBs	8500
Number of Logic Elements/Cells	68000
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	0 °C
Package / Case	900-BBGA
Supplier Device Package	900-FPBGA (31x31)
Total RAM Bits	1056768

Part	Number of Logic Elements/Cells	Mounting Type	Total RAM Bits	Number of I/O	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	Number of LABs/CLBs
LATTICE SEMICONDUCTOR LFE2-70E-6F900C	68000	Surface Mount	1056768	583	900-BBGA	0 °C	85 °C	900-FPBGA (31x31)	8500
LATTICE SEMICONDUCTOR LFE2-70E-6F672I	68000	Surface Mount	1056768	500	672-BBGA	-40 C	100 °C	672-FPBGA (27x27)	8500
LATTICE SEMICONDUCTOR LFE2-70E-6FN900C	68000	Surface Mount	1056768	583	900-BBGA	0 °C	85 °C	900-FPBGA (31x31)	8500
LATTICE SEMICONDUCTOR LFE2-70E-6F900I	68000	Surface Mount	1056768	583	900-BBGA	-40 C	100 °C	900-FPBGA (31x31)	8500
LATTICE SEMICONDUCTOR LFE2-70E-7FN900C	68000	Surface Mount	1056768	583	900-BBGA	0 °C	85 °C	900-FPBGA (31x31)	8500
LATTICE SEMICONDUCTOR LFE2-70E-7F672C	68000	Surface Mount	1056768	500	672-BBGA	0 °C	85 °C	672-FPBGA (27x27)	8500
LATTICE SEMICONDUCTOR LFE2-70E-5FN672C	68000	Surface Mount	1056768	500	672-BBGA	0 °C	85 °C	672-FPBGA (27x27)	8500
LATTICE SEMICONDUCTOR LFE2-70E-5F672C	68000	Surface Mount	1056768	500	672-BBGA	0 °C	85 °C	672-FPBGA (27x27)	8500
LATTICE SEMICONDUCTOR LFE2-70E-5F672I	68000	Surface Mount	1056768	500	672-BBGA	-40 C	100 °C	672-FPBGA (27x27)	8500
LATTICE SEMICONDUCTOR LFE2-70SE-6FN672C	68000	Surface Mount	1056768	500	672-BBGA	0 °C	85 °C	672-FPBGA (27x27)	8500

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	27	$ 332.60
Newark	Each	25	$ 322.79

General part information

ECP2 Field Programmable Gate Array (FPGA) IC 583 1056768 68000 900-BBGA

Technical documentation and resources
