VMS-225-30-1

Active

CUI Inc.

AC/DC CONVERTER 30V 120W

Deep-Dive with AI

Search across all available documentation for this part.

VMS-225-30-1

Active

CUI Inc.

AC/DC CONVERTER 30V 120W

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	VMS-225-30-1

Applications	Medical
Approval Agency	TUV, CB Scheme, UL, FCC, IEC, EN
Current - Output 1	4 A
Efficiency	93 %
Features	Universal Input, Adjustable Output, PFC, Standby Output
Mounting Type	Chassis Mount
Number of Outputs	1
Power (Watts)	225 W, 120 W
Standard Number	61000-3-2, 61000-3-3, 55011 Class B, 60601-1
Type	Open Frame
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	80 VAC
Voltage - Isolation	4.2 kV
Voltage - Output 1	30 V

VMS-225 Series

Part	Features	Current - Output 1	Standard Number	Voltage - Input [Max]	Voltage - Input [Min]	Voltage - Isolation	Approval Agency	Power (Watts)	Applications	Type	Number of Outputs	Efficiency	Mounting Type	Voltage - Output 1
CUI Inc. VMS-225-15-1	Adjustable Output PFC Standby Output Universal Input	8 A	55011 Class B 60601-1 61000-3-2 61000-3-3	264 VAC	80 VAC	4.2 kV	CB Scheme EN FCC IEC TUV UL	120 W 225 W	Medical	Open Frame	1	92 %	Chassis Mount	15 V
CUI Inc. VMS-225-48	Adjustable Output Standby Output Universal Input	2.5 A	55011 Class B 60601-1 61000-3-2 61000-3-3	264 VAC	80 VAC	4.2 kV	CB Scheme EN FCC IEC TUV UL	120 W 225 W	Medical	Open Frame	1	94 %	Chassis Mount	48 V
CUI Inc. VMS-225-30-1	Adjustable Output PFC Standby Output Universal Input	4 A	55011 Class B 60601-1 61000-3-2 61000-3-3	264 VAC	80 VAC	4.2 kV	CB Scheme EN FCC IEC TUV UL	120 W 225 W	Medical	Open Frame	1	93 %	Chassis Mount	30 V
CUI Inc. VMS-225-48-1	Adjustable Output PFC Standby Output Universal Input	2.5 A	55011 Class B 60601-1 61000-3-2 61000-3-3	264 VAC	80 VAC	4.2 kV	CB Scheme EN FCC IEC TUV UL	120 W 225 W	Medical	Open Frame	1	94 %	Chassis Mount	48 V
CUI Inc. VMS-225-12	Adjustable Output Standby Output Universal Input	10 A	55011 Class B 60601-1 61000-3-2 61000-3-3	264 VAC	80 VAC	4.2 kV	CB Scheme EN FCC IEC TUV UL	120 W 225 W	Medical	Open Frame	1	92 %	Chassis Mount	12 V
CUI Inc. VMS-225-24	Adjustable Output Standby Output Universal Input	5 A	55011 Class B 60601-1 61000-3-2 61000-3-3	264 VAC	80 VAC	4.2 kV	CB Scheme EN FCC IEC TUV UL	120 W 225 W	Medical	Open Frame	1	93 %	Chassis Mount	24 V
CUI Inc. VMS-225-12-1	Adjustable Output PFC Standby Output Universal Input	10 A	55011 Class B 60601-1 61000-3-2 61000-3-3	264 VAC	80 VAC	4.2 kV	CB Scheme EN FCC IEC TUV UL	120 W 225 W	Medical	Open Frame	1	92 %	Chassis Mount	12 V
CUI Inc. VMS-225-58-1	Adjustable Output PFC Standby Output Universal Input	2.07 A	55011 Class B 60601-1 61000-3-2 61000-3-3	264 VAC	80 VAC	4.2 kV	CB Scheme EN FCC IEC TUV UL	120 W 225 W	Medical	Open Frame	1	94 %	Chassis Mount
CUI Inc. VMS-225-58	Adjustable Output PFC Standby Output Universal Input	2.07 A	55011 Class B 60601-1 61000-3-2 61000-3-3	264 VAC	80 VAC	4.2 kV	CB Scheme EN FCC IEC TUV UL	120 W 225 W	Medical	Open Frame	1	94 %	Chassis Mount

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	72	$ 159.13

Description

General part information

VMS-225 Series

Open Frame AC DC Converters 1 Output 30V 80 ~ 264 VAC Input
