25054 OR199
ActiveALPHA WIRE
CABLE 4COND 20AWG ORG 1000=1000'
Deep-Dive with AI
Search across all available documentation for this part.
25054 OR199
ActiveALPHA WIRE
CABLE 4COND 20AWG ORG 1000=1000'
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 25054 OR199 | 25054 Series |
|---|---|---|
| Cable Type | Multi-Conductor | Multi-Conductor |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) |
| Conductor Material | Copper, Tinned | Copper, Tinned |
| Conductor Strand [custom] | 28 | 28 |
| Conductor Strand [custom] | 7 | 7 |
| Features | Rip Cord, Biological Compatibility | Rip Cord, Biological Compatibility |
| Jacket (Insulation) Diameter [diameter] | 6.05 mm | 6.05 mm |
| Jacket (Insulation) Diameter [diameter] | 0.238 in | 0.238 in |
| Jacket (Insulation) Material | Polyurethane (PU) | Polyurethane (PU) |
| Jacket Color | Orange | Black, Orange |
| Length | - | Enter Number of Feet in Order Quantity |
| Length | - | 30.5 m |
| Length | - | 100 ft |
| Number of Conductors | 4 | 4 |
| Operating Temperature [Max] | 90 °C | 90 °C |
| Operating Temperature [Min] | -30 ░C | -30 ░C |
| Ratings | UL Style 20668, ISO 10993 | UL Style 20668, ISO 10993 |
| Spool Size | - | 1000 ft |
| Spool Size | - | 304.8 m |
| Voltage | 300 V | 300 V |
| Wire Gauge | 20 AWG | 20 AWG |
25054 Series
CABLE 4COND 20AWG BLACK FEET
| Part | Conductor Strand [custom] | Conductor Strand [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Conductor Insulation | Cable Type | Jacket Color | Wire Gauge | Ratings | Spool Size | Spool Size | Conductor Material | Length | Jacket (Insulation) Material | Voltage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Number of Conductors | Features | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ALPHA WIRE 25054 BK199 | 28 | 7 | -30 ░C | 90 °C | Poly-Vinyl Chloride (PVC) | Multi-Conductor | Black | 20 AWG | ISO 10993, UL Style 20668 | 1000 ft | 304.8 m | Copper, Tinned | Enter Number of Feet in Order Quantity | Polyurethane (PU) | 300 V | 6.05 mm | 0.238 in | 4 | Biological Compatibility, Rip Cord | ||
ALPHA WIRE 25054 OR199 | 28 | 7 | -30 ░C | 90 °C | Poly-Vinyl Chloride (PVC) | Multi-Conductor | Orange | 20 AWG | ISO 10993, UL Style 20668 | Copper, Tinned | Polyurethane (PU) | 300 V | 6.05 mm | 0.238 in | 4 | Biological Compatibility, Rip Cord | |||||
ALPHA WIRE 25054 BK005 | 28 | 7 | -30 ░C | 90 °C | Poly-Vinyl Chloride (PVC) | Multi-Conductor | Black | 20 AWG | ISO 10993, UL Style 20668 | Copper, Tinned | Polyurethane (PU) | 300 V | 6.05 mm | 0.238 in | 4 | Biological Compatibility, Rip Cord | 30.5 m | 100 ft |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
25054 Series
4 Conductor Multi-Conductor Cable Orange 20 AWG
