TMC5031-EVAL-KIT
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT FOR TMC5031
Deep-Dive with AI
Search across all available documentation for this part.
TMC5031-EVAL-KIT
ActiveAnalog Devices Inc./Maxim Integrated
EVAL KIT FOR TMC5031
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | TMC5031-EVAL-KIT | TMC5031 Series |
|---|---|---|
| Applications | - | General Purpose |
| Embedded | MCU, 32-Bit | MCU, 32-Bit |
| Embedded | True | True |
| Function | - | Driver - Fully Integrated, Control and Power Stage |
| Interface | - | SPI |
| Motor Type - Stepper | - | Bipolar |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | -40 °C |
| Operating Temperature | - | 125 ¯C |
| Output Configuration | - | Half Bridge (8) |
| Package / Case | - | 48-VFQFN Exposed Pad |
| Primary Attributes | Motors (Stepper) | Motors (Stepper) |
| Secondary Attributes | Graphical User Interface (GUI) | Graphical User Interface (GUI) |
| Step Resolution | - | 1 |
| Step Resolution | - | 0.00390625 |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 48-QFN (7x7) |
| Technology | - | Power MOSFET |
| Type | Power Management | Power Management |
| Utilized IC / Part | TMC5031 | TMC5031 |
| Voltage - Load | - | 16 V |
| Voltage - Load | - | 4.75 V |
| Voltage - Supply | - | 5 V |
| Voltage - Supply | - | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 133.24 | |
TMC5031 Series
IC MTR DRVR BIPOLAR 3.3-5V 48QFN
| Part | Function | Step Resolution [Max] | Step Resolution [Min] | Voltage - Load [Max] | Voltage - Load [Min] | Voltage - Supply [Max] | Voltage - Supply [Min] | Mounting Type | Interface | Operating Temperature [Min] | Operating Temperature [Max] | Technology | Motor Type - Stepper | Supplier Device Package | Output Configuration | Applications | Package / Case | Utilized IC / Part | Secondary Attributes | Primary Attributes | Embedded | Embedded | Supplied Contents | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated TMC5031-LA-T | Driver - Fully Integrated, Control and Power Stage | 1 | 0.00390625 | 16 V | 4.75 V | 5 V | 3.3 V | Surface Mount | SPI | -40 °C | 125 ¯C | Power MOSFET | Bipolar | 48-QFN (7x7) | Half Bridge (8) | General Purpose | 48-VFQFN Exposed Pad | |||||||
Analog Devices Inc./Maxim Integrated TMC5031-EVAL-KIT | TMC5031 | Graphical User Interface (GUI) | Motors (Stepper) | 32-Bit, MCU | Board(s) | Power Management | ||||||||||||||||||
Analog Devices Inc./Maxim Integrated TMC5031-LA | Driver - Fully Integrated, Control and Power Stage | 1 | 0.00390625 | 16 V | 4.75 V | 5 V | 3.3 V | Surface Mount | SPI | -40 °C | 125 ¯C | Power MOSFET | Bipolar | 48-QFN (7x7) | Half Bridge (8) | General Purpose | 48-VFQFN Exposed Pad | |||||||
Analog Devices Inc./Maxim Integrated TMC5031-EVAL | TMC5031 | Graphical User Interface (GUI) | Motors (Stepper) | 32-Bit, MCU | Board(s) | Power Management |
