50M030050 Series

...

Part	Head Diameter	Drive Type	Thread Pitch	Thread Diameter	Type	Length - Overall	Screw Head Type	Material	Length - Below Head	Head Height
Essentra Components 50M030050K004	0.197 in	Slotted	0.5 mm	3 mm	Bolt	0.248 in	Hex Head	Nylon	0.157 in
Essentra Components 50M030050D035	0.217 in	Slotted	0.5 mm	3 mm	Bolt	1.457 in	Cheese Head	Nylon	1.378 in	0.079 in
Essentra Components 50M030050T020	0.317 in	Slotted	0.5 mm	3 mm	Thumb Screw	1.003 in	Knob	Nylon	0.787 in	0.216 in
Essentra Components 50M030050D010	0.217 in	Slotted	0.5 mm	3 mm	Bolt	0.472 in	Cheese Head	Nylon	0.394 in	0.079 in
Essentra Components 50M030050D012	0.217 in	Slotted	0.5 mm	3 mm	Bolt	0.551 in	Cheese Head	Nylon	0.472 in	0.079 in
Essentra Components 50M030050T016	0.317 in	Slotted	0.5 mm	3 mm	Thumb Screw	0.846 in	Knob	Nylon	0.63 in	0.216 in
Essentra Components 50M030050M008	0.248 in	Phillips	0.5 mm	3 mm	Machine Screw	0.343 in	Oval Head	Nylon	0.248 in	0.094 in
Essentra Components 50M030050H015	0.248 in	Slotted	0.5 mm	3 mm	Machine Screw	0.591 in	Flat Head	Nylon	0.524 in	0.067 in
Essentra Components 50M030050J025	0.197 in	Hex Socket	0.5 mm	3 mm	Bolt	1.075 in	Hex Head	Nylon	0.984 in
Essentra Components 50M030050J004	0.197 in	Hex Socket	0.5 mm	3 mm	Bolt	0.248 in	Hex Head	Nylon	0.157 in
