4936(1"X72YD)

Active

3M (TC)

TAPE DBL SIDED GRAY 1"X72YDS

Search across all available documentation for this part.

Active

3M (TC)

TAPE DBL SIDED GRAY 1"X72YDS

Technical Specifications

Parameters and characteristics for this part

Specification	4936(1"X72YD)

Adhesive	Acrylic
Backing, Carrier	Acrylic Foam
Color	Gray
Length	66 m
Length	216 ft
Length	72 yd
Shelf Life	24 Months
Shelf Life Start	Date of Shipment
Storage/Refrigeration Temperature [Max]	100 °F, 38 °C
Storage/Refrigeration Temperature [Min]	40 °F, 4 °C
Tape Type	Double Coated, Double Sided
Thickness	0.508 mm
Thickness	0.02 in
Thickness	0.508 mm
Thickness - Backing, Carrier	0.003 in
Thickness - Backing, Carrier	3 mils
Thickness - Backing, Carrier	0.076 mm
Usage	General Purpose
Width [x]	25.4 mm
Width [x]	1 in

Part	Thickness - Backing, Carrier [custom]	Thickness - Backing, Carrier [custom]	Thickness - Backing, Carrier [custom]	Adhesive	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Thickness	Thickness	Thickness	Usage	Width	Width	Width	Length	Length	Length	Tape Type	Color	Shelf Life	Temperature Range	Temperature Range	Shelf Life Start	Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Width [x]	Width [x]
3M (TC) 4936F-3/4"X72YD SM PK	0.005 "	5 mils	0.127 mm	Acrylic	20 mils	0.508 mm	0.02 "	4 °C 40 °F	38 °C 100 °F	0.635 mm	0.635 mm	0.025 in	General Purpose	0.75 in	19.05 mm	0.75 in	66 m	216 ft	72 yd	Double Coated Double Sided	Gray	24 Months	200 °F	93 °C	Date of Shipment
3M (TC) 4936F-GRAY-1/2"X72YD	0.005 "	5 mils	0.127 mm	Acrylic	20 mils	0.508 mm	0.02 "	4 °C 40 °F	38 °C 100 °F	0.635 mm	0.635 mm	0.025 in	General Purpose	0.5 in	0.5 in	12.7 mm	66 m	216 ft	72 yd	Double Coated Double Sided	Gray	24 Months	200 °F	93 °C	Date of Shipment
3M (TC) 4936(1"X72YD)				Acrylic				4 °C 40 °F	38 °C 100 °F	0.508 mm	0.508 mm	0.02 in	General Purpose				66 m	216 ft	72 yd	Double Coated Double Sided	Gray	24 Months			Date of Shipment	Acrylic Foam	0.003 in	3 mils	0.076 mm	25.4 mm	1 in
3M (TC) 4936F(1"X72YD)	0.005 "	5 mils	0.127 mm	Acrylic				4 °C 40 °F	38 °C 100 °F	0.508 mm	0.508 mm	0.02 in	General Purpose				66 m	216 ft	72 yd	Double Coated Double Sided	Gray	24 Months			Date of Shipment	Paper				25.4 mm	1 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	9	$ 316.48

General part information

Double Coated, Double Sided Tape Acrylic Adhesive Gray 1.00" (25.40mm) X 216' (66.0m) 72 yds
