Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1000 | $ 1.39 | |
General part information
8 (4 Pair) Conductor Multi-Pair, Cat6a Cable Red 23 AWG 1000.0' (304.8m)
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 10GXS13002A1000 | 10GXS13 Series |
|---|---|---|
| - | - | |
| Cable Type | Multi-Pair, Cat6a | Multi-Pair, Cat6a |
| Conductor Insulation | Fluorinated Ethylene-Propylene (FEP) | Fluorinated Ethylene-Propylene (FEP) |
| Conductor Material | Copper, Bare | Copper, Bare |
| Conductor Strand | Solid | Solid |
| Features | Rip Cord | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 6.73 mm | 6.73 mm |
| Jacket (Insulation) Diameter [diameter] | 0.265 in | 0.265 in |
| Jacket (Insulation) Material | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum |
| Jacket Color | Red | Red, Gray, Green, Orange, Black |
| Length | 1000 ft | 1000 ft |
| Length | 304.8 m | 304.8 m |
| Number of Conductors | 8 | 8 |
| Ratings | UL Style CMP | UL Style CMP |
| Usage | Network | Network |
| Voltage | 300 V | 300 V |
| Wire Gauge | 23 AWG | 23 AWG |
CAT6A 4PR U/UTP CMP REEL
| Part | Conductor Strand | Number of Conductors | Usage | Cable Type | Jacket (Insulation) Material | Length | Length | Ratings | Features | Conductor Insulation | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Material | Wire Gauge | Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 10GXS13 0021000 | Solid | 8 | Network | Multi-Pair, Cat6a | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 1000 ft | 304.8 m | UL Style CMP | Rip Cord | Fluorinated Ethylene-Propylene (FEP) | Red | 6.73 mm | 0.265 in | Copper, Bare | 23 AWG | 300 V |
Belden Inc. 10GXS13 0081000 | Solid | 8 | Network | Multi-Pair, Cat6a | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 1000 ft | 304.8 m | UL Style CMP | Rip Cord | Fluorinated Ethylene-Propylene (FEP) | Gray | 6.73 mm | 0.265 in | Copper, Bare | 23 AWG | 300 V |
Belden Inc. 10GXS13002A1000 | Solid | 8 | Network | Multi-Pair, Cat6a | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 1000 ft | 304.8 m | UL Style CMP | Rip Cord | Fluorinated Ethylene-Propylene (FEP) | Red | 6.73 mm | 0.265 in | Copper, Bare | 23 AWG | 300 V |
Belden Inc. 10GXS13 0051000 | Solid | 8 | Network | Multi-Pair, Cat6a | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 1000 ft | 304.8 m | UL Style CMP | Rip Cord | Fluorinated Ethylene-Propylene (FEP) | Green | 6.73 mm | 0.265 in | Copper, Bare | 23 AWG | 300 V |
Belden Inc. 10GXS13008A1000 | Solid | 8 | Network | Multi-Pair, Cat6a | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 1000 ft | 304.8 m | UL Style CMP | Rip Cord | Fluorinated Ethylene-Propylene (FEP) | Gray | 6.73 mm | 0.265 in | Copper, Bare | 23 AWG | 300 V |
Belden Inc. 10GXS13003A1000 | Solid | 8 | Network | Multi-Pair, Cat6a | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 1000 ft | 304.8 m | UL Style CMP | Rip Cord | Fluorinated Ethylene-Propylene (FEP) | Orange | 6.73 mm | 0.265 in | Copper, Bare | 23 AWG | 300 V |
Belden Inc. 10GXS13010A1000 | Solid | 8 | Network | Multi-Pair, Cat6a | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 1000 ft | 304.8 m | UL Style CMP | Rip Cord | Fluorinated Ethylene-Propylene (FEP) | Black | 6.73 mm | 0.265 in | Copper, Bare | 23 AWG | 300 V |
Belden Inc. 10GXS13009U1000 |
