440133-2
ActiveTE Connectivity AMP Connectors
CONNECTOR HOUSING, RCPT, 2POS, 2.5MM ROHS COMPLIANT: YES
440133-2
ActiveTE Connectivity AMP Connectors
CONNECTOR HOUSING, RCPT, 2POS, 2.5MM ROHS COMPLIANT: YES
Description
General part information
440133 Series
2 Position, Receptacle, Housing, Crimp, Wire-to-Wire, UL 94V-0, 2.5 mm [.098 in] Centerline, 1 Row, 250 VAC, Wire & Cable, Power & Signal, HPI
Technical Specifications
Parameters and characteristics for this part
| Specification | 440133-2 |
|---|---|
| Color | Natural |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Insulation Material | Polyamide (PA66), Nylon 6/6 |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -25 °C |
| Pitch | 0.098 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
Drawing EN
VAL-U-LOK Connectors
ENG_CD_440133_B1.pdf
AMP 2.5mm Pitch HPI (Low Cost) W-to-B System Test Report
AMP 2.5mm Pitch HPI High Performance Interconnect (Low Cost) Wire-to-Board System
Datasheet
VAL-U-LOK
FEMALE, MALE, PLUG, RECEPTACLE CONNECTOR AND HEADER REPORT
AMP 2.5MM PITCH HPI WIRE TO BOARD SYSTEM.
HPI Connectors QRG
Metric Interconnect System (Restricted to Sony Corporation)
2.5MM PITCH HPI CRIMP HOUSING.
