SNDHS250B03

Active

Cosel USA, Inc.

DC/DC CONVERTER 3.3V 165W

Search across all available documentation for this part.

Active

Cosel USA, Inc.

DC/DC CONVERTER 3.3V 165W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Output 1	Approval Agency	Applications	Type	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Number of Outputs	Current - Output (Max) [Max]	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Input (Max) [Max]	Power (Watts)	Voltage - Input (Min) [Min]	Efficiency
Cosel USA, Inc. SNDHS250B12	12 V	CE cURus	ITE (Commercial)	Open Frame	2.42 in	1.75 "	5 in	61.5 mm	127 mm	44.5 mm	1	21 A	Chassis Mount	-20 °C	95 °C	400 V	252 W	200 V	86 %
Cosel USA, Inc. SNDHS250B03	3.3 V	CE cURus	ITE (Commercial)	Open Frame	2.42 in	1.75 "	5 in	61.5 mm	127 mm	44.5 mm	1	50 A	Chassis Mount	-20 °C	95 °C	400 V	165 W	200 V	86 %
Cosel USA, Inc. SNDHS250B05	5 V	CE cURus	ITE (Commercial)	Open Frame	2.42 in	1.75 "	5 in	61.5 mm	127 mm	44.5 mm	1	50 A	Chassis Mount	-20 °C	95 °C	400 V	250 W	200 V	88 %
Cosel USA, Inc. SNDHS250B24	24 V	CE cURus	ITE (Commercial)	Open Frame	2.42 in	1.75 "	5 in	61.5 mm	127 mm	44.5 mm	1	10.5 A	Chassis Mount	-20 °C	95 °C	400 V	252 W	200 V	86 %
Cosel USA, Inc. SNDHS250B15	15 V	CE cURus	ITE (Commercial)	Open Frame	2.42 in	1.75 "	5 in	61.5 mm	127 mm	44.5 mm	1	16.5 A	Chassis Mount	-20 °C	95 °C	400 V	248 W	200 V	86 %
Cosel USA, Inc. SNDHS250B48	48 V	CE cURus	ITE (Commercial)	Open Frame	2.42 in	1.75 "	5 in	61.5 mm	127 mm	44.5 mm	1	5.2 A	Chassis Mount	-20 °C	95 °C	400 V	250 W	200 V	87 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 304.58

General part information

Open Frame DC DC Converter 1 Output 3.3V 50A 400V Input
