FF150R12KE3GHOSA1

Active

Infineon Technologies

THE FF150R12KE3G IS A DUAL IGBT3 - E3 MODULE IN A 62 MM HOUSING FOR INDUSTRIAL APPLICATIONS UP TO 1200 V AND 150 A.

Search across all available documentation for this part.

Active

Infineon Technologies

THE FF150R12KE3G IS A DUAL IGBT3 - E3 MODULE IN A 62 MM HOUSING FOR INDUSTRIAL APPLICATIONS UP TO 1200 V AND 150 A.

Technical Specifications

Parameters and characteristics for this part

Specification	FF150R12KE3GHOSA1

Configuration	Single Chopper
Current - Collector (Ic) (Max) [Max]	225 A
Current - Collector Cutoff (Max) [Max]	5 mA
IGBT Type	Trench Field Stop
Input	Standard
Input Capacitance (Cies) @ Vce	11 nF
Mounting Type	Chassis Mount
NTC Thermistor	False
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Package / Case	Module
Power - Max [Max]	780 W
Supplier Device Package	Module
Vce(on) (Max) @ Vge, Ic	2.15 V
Voltage - Collector Emitter Breakdown (Max) [Max]	1200 V

Part	Vce(on) (Max) @ Vge, Ic	Configuration	Mounting Type	Package / Case	Input Capacitance (Cies) @ Vce	Input	Current - Collector (Ic) (Max) [Max]	Power - Max [Max]	IGBT Type	Voltage - Collector Emitter Breakdown (Max) [Max]	Current - Collector Cutoff (Max) [Max]	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]
Infineon Technologies FF150R12KE3GHOSA1	2.15 V	Single Chopper	Chassis Mount	Module	11 nF	Standard	225 A	780 W	Trench Field Stop	1200 V	5 mA	Module	125 °C	-40 °C
Infineon Technologies FF150R12KE3GB2HOSA1	2.15 V	Half Bridge Inverter	Chassis Mount	Module	11 nF	Standard	225 A	780 W	Trench Field Stop	1200 V	5 mA	Module	125 ¯C	-40 °C
Infineon Technologies FF150R12KT3GHOSA1	2.15 V	Single Chopper	Chassis Mount	Module	11 nF	Standard	225 A	780 W	Trench Field Stop	1200 V	5 mA	Module	125 °C	-40 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

62 mm1200 V, 150 A dualIGBT modulewith TRENCHSTOP™ IGBT3 and emitter controlled high efficiency diode.
