C276CAA4630AE0J

Active

KEMET

CAP FILM 6.3UF 5% 470VAC RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP FILM 6.3UF 5% 470VAC RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	C276CAA4630AE0J

Applications	Motor Run
Dielectric Material	Metallized, Polypropylene (PP)
Height - Seated (Max) [Max] [z]	57 mm
Height - Seated (Max) [Max] [z]	2.244 "
Mounting Type	Through Hole
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Package / Case	Radial, Can
Size / Dimension [diameter]	30 mm
Size / Dimension [diameter]	1.181 inches
Termination	Wire Leads
Tolerance	5 %
Voltage Rating - AC	470 V

Part	Capacitance	Termination	Termination	Termination	Applications	Size / Dimension [diameter]	Size / Dimension [diameter]	Voltage Rating - AC	Tolerance	Mounting Type	Dielectric Material	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Lead Spacing	Lead Spacing
KEMET C276CA35350AA0J	35 µF	0.25 in	6.3 mm	Quick Connect	Motor Run	45 mm	1.772 in	470 V	5 %	Through Hole	Metallized Polypropylene (PP)	3.799 "	96.5 mm	-25 °C	85 °C	Radial Can	13.4 mm	0.528 in
KEMET C276CAA4630AE0J				Wire Leads	Motor Run	30 mm	1.181 inches	470 V	5 %	Through Hole	Metallized Polypropylene (PP)	2.244 "	57 mm	-25 °C	85 °C	Radial Can
KEMET C276CAA4800AV1J	8 µF			Wire Leads	Motor Run	35 mm	1.378 in	470 V	5 %	Through Hole	Metallized Polypropylene (PP)	2.244 "	57 mm	-25 °C	85 °C	Radial Can

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

6.3 µF Film Capacitor 470V Polypropylene (PP), Metallized Radial, Can
