AA10S0300A

Obsolete

Delta Electronics

AC/DC CONVERTER 3.3V 10W

Search across all available documentation for this part.

Obsolete

Delta Electronics

AC/DC CONVERTER 3.3V 10W

Technical Specifications

Parameters and characteristics commom to parts in this series

AC/DC CONVERTER 15V 10W

Part	Applications	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Line Regulation	Features	Weight	Weight	Voltage - Output 1	Efficiency	Current - Output (Max) [Max]	Number of Outputs	Standard Number	Package / Case	Power (Watts)	Type	Load Regulation	Mounting Type	Approval Agency	Operating Temperature [Min]	Operating Temperature [Max]
Delta Electronics AA10S1500A	ITE (Commercial)	2.06 in	23.5 mm	52.3 mm	0.93 in	27.2 mm	1.07 in	0.5 %	Universal Input	0.119 lb	53.98 g	15 V	75 %	667 mA	1	60950-1	4-DIP Module	10 W	Enclosed	0.5 %	Through Hole	CE, UL	-25 °C	70 °C
Delta Electronics AA10S2400A	ITE (Commercial)	2.06 in	23.5 mm	52.3 mm	0.93 in	27.2 mm	1.07 in	0.5 %	Universal Input	0.119 lb	53.98 g	24 V	72 %		1	60950-1	4-DIP Module	10 W	Enclosed	0.5 %	Through Hole	CE, UL	-25 °C	70 °C
Delta Electronics AA10S0300A	ITE (Commercial)	2.06 in	23.5 mm	52.3 mm	0.93 in	27.2 mm	1.07 in	0.5 %	Universal Input	0.119 lb	53.98 g	3.3 V	70 %	2.5 A	1	60950-1	4-DIP Module	10 W	Enclosed	0.5 %	Through Hole	CE, UL	-25 °C	70 °C
Delta Electronics AA10S1200A	ITE (Commercial)	2.06 in	23.5 mm	52.3 mm	0.93 in	27.2 mm	1.07 in	0.5 %	Universal Input	0.119 lb	53.98 g	12 V	76 %	833 mA	1	60950-1	4-DIP Module	10 W	Enclosed	0.5 %	Through Hole	CE, UL	-25 °C	70 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 1 Output 3.3V 2.5A 85 ~ 264 VAC Input
