ZXFV201EV

Active

Diodes Inc

EVAL BOARD FOR ZXFV201

Search across all available documentation for this part.

Active

Diodes Inc

EVAL BOARD FOR ZXFV201

Technical Specifications

Parameters and characteristics for this part

Specification	ZXFV201EV

-3db Bandwidth	210 MHz
Amplifier Type	Video
Board Type	Fully Populated
Channels per IC	4
Current - Output / Channel [custom]	40 mA
Current - Supply (Main IC)	7.5 mA
Output Type	Single-Ended
Slew Rate	600 V/µs
Supplied Contents	Board(s)
Utilized IC / Part	ZXFV201
Voltage - Supply, Single/Dual (±) [Max]	5.25 V
Voltage - Supply, Single/Dual (±) [Min]	-4.75 V

Part	Slew Rate	Current - Supply (Main IC)	Output Type	Board Type	Amplifier Type	Utilized IC / Part	Supplied Contents	Channels per IC	Voltage - Supply, Single/Dual (±) [Min]	Voltage - Supply, Single/Dual (±) [Max]	-3db Bandwidth	Current - Output / Channel [custom]
Diodes Inc ZXFV201EV	600 V/µs	7.5 mA	Single-Ended	Fully Populated	Video	ZXFV201	Board(s)	4	-4.75 V	5.25 V	210 MHz	40 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	N/A	1	$ 69.54

General part information

ZXFV201 4 - Quad Channels per IC Video Amplifier Evaluation Board
