HC90AY-1
ActiveBourns Inc.
THERMOSTAT 90DEG C NC 2-SMD SLDR
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
HC90AY-1
ActiveBourns Inc.
THERMOSTAT 90DEG C NC 2-SMD SLDR
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | HC90AY-1 |
|---|---|
| Approval Agency | cUL, TUV, UL |
| Current Rating (Amps) | 25 A |
| Package / Case | Nonstandard |
| Rated Functioning Temperature | 194 °F |
| Rated Functioning Temperature | 90 °C |
| Reset Temperature | 104 °F |
| Reset Temperature | 40 °C |
| Type | Breaker |
| Voltage Rating - DC | 28 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 1.79 | |
| 5 | $ 1.49 | |||
| 10 | $ 1.38 | |||
| 50 | $ 1.15 | |||
| 100 | $ 1.06 | |||
| 250 | $ 0.96 | |||
| 500 | $ 0.88 | |||
| 1000 | $ 0.82 | |||
| 5000 | $ 0.68 | |||
Description
General part information
HC90AY Series
Thermal Cutoff (TCO) AC DC 25 A 90°C (194°F) Nonstandard
