Specification	TMR 4-4811

Applications	ITE (Commercial)
Approval Agency	UL, CB, cURus
Current - Output (Max)	800 mA
Efficiency	80 %
Features	Remote On/Off
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package Leads	7 Leads
Package Name	8-SIP Module
Power (Watts)	4 W
Size / Dimension Height	0.44 in
Size / Dimension Length	0.86 in
Size / Dimension Width	0.37 in
Type	Isolated Module
Voltage - Input (Max)	75 V
Voltage - Input (Min)	36 V
Voltage - Isolation	1.92 kV
Voltage - Output 1	5 V

TMR 4 Series

Part	Size / Dimension Height	Size / Dimension Length	Size / Dimension Width	Voltage - Input (Min)	Mounting Type	Number of Outputs	Efficiency	Type	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Output 1	Power (Watts)	Current - Output (Max)	Package Leads	Package Name	Applications	Approval Agency	Voltage - Isolation	Voltage - Input (Max)	Features	Voltage - Output 2
Traco Power TMR 4-4813	0.44 in	0.86 in	0.37 in	36 V	Through Hole	1	83 %	Isolated Module	-40 °C	85 °C	15 V	4 W	266 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	75 V	Remote On/Off
Traco Power TMR 4-2422WI	0.44 in	0.86 in	0.37 in	9 V	Through Hole	2	83 %	Isolated Module	-40 °C	85 °C	12 V	4 W	166 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	36 V	Remote On/Off	-12 V
Traco Power TMR 4-4822WI	0.44 in	0.86 in	0.37 in	18 V	Through Hole	2	82 %	Isolated Module	-40 °C	85 °C	12 V	4 W	166 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	75 V	Remote On/Off	-12 V
Traco Power TMR 4-4823WI	0.44 in	0.86 in	0.37 in	18 V	Through Hole	2	82 %	Isolated Module	-40 °C	85 °C	15 V	4 W	133 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	75 V	Remote On/Off	-15 V
Traco Power TMR 4-2412WI	0.44 in	0.86 in	0.37 in	9 V	Through Hole	1	83 %	Isolated Module	-40 °C	85 °C	12 V	4 W	333 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	36 V	Remote On/Off
Traco Power TMR 4-2412	0.44 in	0.86 in	0.37 in	18 V	Through Hole	1	86 %	Isolated Module	-40 °C	85 °C	12 V	4 W	333 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	36 V	Remote On/Off
Traco Power TMR 4-4811WI	0.44 in	0.86 in	0.37 in	18 V	Through Hole	1	78 %	Isolated Module	-40 °C	85 °C	5 V	4 W	800 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	75 V	Remote On/Off
Traco Power TMR 4-1223	0.44 in	0.86 in	0.37 in	9 V	Through Hole	2	86 %	Isolated Module	-40 °C	85 °C	15 V	4 W	133 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	18 V	Remote On/Off	-15 V
Traco Power TMR 4-4811	0.44 in	0.86 in	0.37 in	36 V	Through Hole	1	80 %	Isolated Module	-40 °C	85 °C	5 V	4 W	800 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	75 V	Remote On/Off
Traco Power TMR 4-2415WI	0.44 in	0.86 in	0.37 in	9 V	Through Hole	1	83 %	Isolated Module	-40 °C	85 °C	24 V	4 W	166 mA	7 Leads	8-SIP Module	ITE (Commercial)	CB cURus UL	1.92 kV	36 V	Remote On/Off
