HEP-150-54A
ActiveMEAN WELL USA Inc.
AC/DC CONVERTER 54V 151W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
HEP-150-54A
ActiveMEAN WELL USA Inc.
AC/DC CONVERTER 54V 151W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | HEP-150-54A |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CB, cURus, CE |
| Current - Output 1 | 2.8 A |
| Efficiency | 94 % |
| Features | PFC, Adjustable Output, IP65 |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -55 °C |
| Power (Watts) | 151 W |
| Size / Dimension [x] | 228 mm |
| Size / Dimension [x] | 8.98 " |
| Size / Dimension [y] | 2.68 " |
| Size / Dimension [y] | 68 mm |
| Size / Dimension [z] | 38.8 mm |
| Size / Dimension [z] | 1.53 in |
| Type | Enclosed |
| Voltage - Input [Max] | 305 VAC, 431 VDC |
| Voltage - Input [Min] | 90 VAC, 127 VDC |
| Voltage - Isolation | 3750 V |
| Voltage - Output 1 | 54 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 82.70 | |
| 5 | $ 78.70 | |||
| 10 | $ 75.30 | |||
| 25 | $ 73.10 | |||
Description
General part information
HEP-150 Series
Enclosed AC DC Converters 1 Output 54V 90 ~ 305 VAC, 127 ~ 431 VDC Input
