P2022YP

Obsolete

NKK Switches

SWITCH ROCKER DPDT 10A 125V

Search across all available documentation for this part.

Obsolete

NKK Switches

SWITCH ROCKER DPDT 10A 125V

Technical Specifications

Parameters and characteristics for this part

Part	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Switch Function	Electrical Life	Actuator Marking	Circuit	Actuator Type	Approval Agency	Mounting Type	Termination Style	Voltage Rating - AC	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Color - Actuator/Cap
NKK Switches P2022Y	10 A	-10 °C	85 °C	On-On	25000 Steps	Varies by Cap	DPDT	Actuator Arm Cap Required	CSA UL VDE	Flange Panel Mount	Solder Lug	125 V	28.5 mm	16 mm
NKK Switches P2022YP	10 A	-10 °C	85 °C	On-On	25000 Steps	Varies by Cap	DPDT	Actuator Arm Cap Required	CSA UL VDE	Flange Panel Mount	PC Pin	125 V	28.5 mm	16 mm
NKK Switches P2022YZ-JC	10 A	-10 °C	85 °C	On-On	25000 Steps	No Marking	DPDT	Concave (Standard V)	CSA UL VDE	Flange Panel Mount	Quick Connect - 0.187" (4.7mm)	125 V	28.5 mm	16 mm	Red

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 14.22

General part information

Rocker Switch DPDT 10A (AC) 125 V Panel Mount, Flange

Technical documentation and resources
