CUS60M-12/CO

Active

TDK-LAMBDA

AC/DC OPEN FRAME POWER SUPPLY (PSU), ITE, HOUSEHOLD & MEDICAL, 1 OUTPUT, 60 W, 85V AC TO 265V AC

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet User Manual EN +3

CUS60M-12/CO

Active

TDK-LAMBDA

AC/DC OPEN FRAME POWER SUPPLY (PSU), ITE, HOUSEHOLD & MEDICAL, 1 OUTPUT, 60 W, 85V AC TO 265V AC

Deep-Dive with AI

DocumentsDatasheet User Manual EN +3

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CUS60M-12/CO

Applications	Household Appliances, ITE (Commercial), Medical
Approval Agency	CE
Current - Output 1	5 A
Efficiency	88 %
Features	Adjustable Output, Universal Input
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 °C
Size / Dimension [x]	3 "
Size / Dimension [x]	76.2 mm
Size / Dimension [y]	50.8 mm
Size / Dimension [y]	2 in
Size / Dimension [z]	24.2 mm
Size / Dimension [z]	24.13 mm
Type	Open Frame, Conformal Coated
Voltage - Input [Max]	265 VAC
Voltage - Input [Min]	85 VAC
Voltage - Isolation	4000 V
Voltage - Output 1	12 V

CUS60M Series

Part	Voltage - Isolation	Number of Outputs	Type	Current - Output 1	Voltage - Input [Min]	Voltage - Input [Max]	Approval Agency	Efficiency	Mounting Type	Features	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output 1	Applications	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Power (Watts)	Load Regulation	Current - Output (Max) [Max]	Package / Case	Line Regulation
TDK-LAMBDA CUS60M-24	4000 V	1	Open Frame	2.5 A	85 VAC	265 VAC	CE	90 %	Chassis Mount	PFC Remote Sense	-20 °C	70 °C	24 V	ITE (Commercial) Medical	1.05 "	26.7 mm	3 "	76.2 mm	50.8 mm	2 in
TDK-LAMBDA CUS60M-24/M	4000 V	1	Open Frame	2.5 A	85 VAC	265 VAC	CE	90 %	Chassis Mount	Adjustable Output Universal Input	-20 °C	70 °C	24 V	Household Appliances ITE (Commercial) Medical	24.13 mm	24.2 mm	3 "	76.2 mm	50.8 mm	2 in
TDK-LAMBDA CUS60M-18	4000 V	1	Open Frame	3.25 A	85 VAC	265 VAC	CE	89 %	Chassis Mount	PFC Remote Sense	-20 °C	70 °C	18 V	ITE (Commercial) Medical	1.05 "	26.7 mm	3 "	76.2 mm	50.8 mm	2 in	59 W
TDK-LAMBDA CUS60M-12/P		1	Open Frame		85 VAC	265 VAC	CE	88 %	Through Hole	Adjustable Output Universal Input	-20 °C	70 °C	12 V	Household Appliances ITE (Commercial) Medical	24.13 mm	24.2 mm	3 "	76.2 mm	50.8 mm	2 in	60 W	120 mV	5 A	6-DIP Module	48 mV
TDK-LAMBDA CUS60M-15	4000 V	1	Open Frame	4 A	85 VAC	265 VAC	CE	89 %	Chassis Mount	PFC Remote Sense	-20 °C	70 °C	15 V	ITE (Commercial) Medical	1.05 "	26.7 mm	3 "	76.2 mm	50.8 mm	2 in
TDK-LAMBDA CUS60M-12/CO	4000 V	1	Conformal Coated Open Frame	5 A	85 VAC	265 VAC	CE	88 %	Chassis Mount	Adjustable Output Universal Input	-20 °C	70 °C	12 V	Household Appliances ITE (Commercial) Medical	24.13 mm	24.2 mm	3 "	76.2 mm	50.8 mm	2 in
TDK-LAMBDA CUS60M-24/CO	4000 V	1	Conformal Coated Open Frame	2.5 A	85 VAC	265 VAC	CE	90 %	Chassis Mount	Adjustable Output Universal Input	-20 °C	70 °C	24 V	Household Appliances ITE (Commercial) Medical	24.13 mm	24.2 mm	3 "	76.2 mm	50.8 mm	2 in
TDK-LAMBDA CUS60M-18/SF	4000 V	1	Open Frame	3.25 A	85 VAC	265 VAC	CE	88 %	Chassis Mount	Adjustable Output Universal Input	-20 °C	70 °C	18 V	Household Appliances ITE (Commercial) Medical	24.13 mm	24.2 mm	3 "	76.2 mm	50.8 mm	2 in	59 W
TDK-LAMBDA CUS60M-24/SF	4000 V	1	Open Frame	2.5 A	85 VAC	265 VAC	CE	90 %	Chassis Mount	Adjustable Output Universal Input	-20 °C	70 °C	24 V	Household Appliances ITE (Commercial) Medical	24.13 mm	24.2 mm	3 "	76.2 mm	50.8 mm	2 in
TDK-LAMBDA CUS60M-18/M	4000 V	1	Open Frame	3.25 A	85 VAC	265 VAC	CE	88 %	Chassis Mount	Adjustable Output Universal Input	-20 °C	70 °C	18 V	Household Appliances ITE (Commercial) Medical	24.13 mm	24.2 mm	3 "	76.2 mm	50.8 mm	2 in	59 W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 43.81
Newark	Each	1	$ 43.81
		10	$ 40.69
		25	$ 38.50
		50	$ 36.61

Description

General part information

CUS60M Series

Open Frame, Conformal Coated AC DC Converters 1 Output 12V 85 ~ 265 VAC Input
