AVT34323
ActivePanasonic Electric Works
SWITCH SNAP ACTION SPDT 3A 125V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsHow to Read Date Codes
AVT34323
ActivePanasonic Electric Works
SWITCH SNAP ACTION SPDT 3A 125V
Deep-Dive with AI
DocumentsHow to Read Date Codes
Technical Specifications
Parameters and characteristics for this part
| Specification | AVT34323 |
|---|---|
| Actuator Type | Lever, Straight |
| Circuit | SPDT |
| Current Rating (Amps) | 3 A |
| Differential Travel | 1 mm |
| Differential Travel | 0.04 in |
| Electrical Life | 50000 Cycles |
| Mechanical Life | 500000 Cycles |
| Mounting Type | Through Hole |
| Operating Position | 8.8 mm |
| Operating Position | 0.345 in |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -25 °C |
| Overtravel | 1.6 mm |
| Overtravel | 0.062 in |
| Pretravel | 0.138 in |
| Pretravel | 3.5 mm |
| Release Force | 1.224 gf |
| Switch Function | On-Mom |
| Termination Style | PC Pin |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 30 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 1.30 | |
| 10 | $ 1.23 | |||
| 25 | $ 1.18 | |||
| 50 | $ 1.13 | |||
| 100 | $ 1.08 | |||
| 300 | $ 0.86 | |||
Description
General part information
AVT343 Series
Switch SPDT Through Hole
