3072Z 0105000

Active

Belden Inc.

CABLE 2COND 18AWG BLK SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 18AWG BLK SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	3072Z 0105000

Cable Type	Multi-Conductor
Conductor Insulation	Polyolefin (PO)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	26 AWG
Conductor Strand [custom]	7
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	10.62 mm
Jacket (Insulation) Diameter [diameter]	0.418 in
Jacket Color	Black
Number of Conductors	2
Shield Coverage	100 %, 55 %
Shield Material	Copper, Tinned, Aluminum
Shield Type	Foil, Braid
Wire Gauge	18 AWG

Part	Jacket Color	Conductor Strand [custom]	Conductor Strand [custom]	Shield Coverage	Number of Conductors	Conductor Insulation	Features	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Shield Type	Shield Material	Wire Gauge	Conductor Material	Cable Type
Belden Inc. 3072Z 0105000	Black	26 AWG	7	55 % 100 %	2	Polyolefin (PO)	Drain Wire	10.62 mm	0.418 in	Braid Foil	Aluminum Copper Tinned	18 AWG	Copper Tinned	Multi-Conductor

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	5000	$ 9.81

General part information

2 (1 Pair Twisted) Conductor Multi-Conductor Cable Black 18 AWG Foil, Braid 5000' (1524.0m)
