KMT40-51212
TDK-LAMBDA
AC/DC PCB MOUNT POWER SUPPLY (PSU), MEDICAL, 3 OUTPUT, 40 W, 5 V, 5 A, 12 V
Deep-Dive with AI
Search across all available documentation for this part.
KMT40-51212
TDK-LAMBDA
AC/DC PCB MOUNT POWER SUPPLY (PSU), MEDICAL, 3 OUTPUT, 40 W, 5 V, 5 A, 12 V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | KMT40-51212 |
|---|---|
| Applications | Medical |
| Approval Agency | IEC, CE, EN, UL |
| Current - Output (Max) | 600 mA, 5 A |
| Efficiency | 80 % |
| Features | Universal Input |
| Line Regulation | 5 %, 0.5 % |
| Mounting Type | Through Hole |
| Number of Outputs | 3 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | 7-DIP Module |
| Power (Watts) | 40 W |
| Size / Dimension [x] | 89 mm |
| Size / Dimension [x] | 3.5 in |
| Size / Dimension [y] | 2.5 in |
| Size / Dimension [y] | 63.5 mm |
| Size / Dimension [z] | 27 mm |
| Size / Dimension [z] | 1.06 in |
| Standard Number | 60950-1, 60601-1, 62368-1 |
| Type | Enclosed |
| Voltage - Input [Max] | 375 VDC, 264 VAC |
| Voltage - Input [Min] | 90 VAC, 100 V |
| Voltage - Output 1 | 5 V |
| Weight | 280.32 g |
| Weight | 0.618 lb |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
KMT40 Series
Enclosed AC DC Converters 3 Output 5V 5A, 600mA, 600mA 90 ~ 264 VAC, 100 ~ 375 VDC Input
