PCH-124D2H,000

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE SPDT 5A 24V

Search across all available documentation for this part.

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE SPDT 5A 24V

Technical Specifications

Parameters and characteristics for this part

Part	Release Time	Operate Time	Switching Voltage	Load - Max Switching	Coil Type	Termination Style	Coil Voltage	Must Release Voltage	Contact Rating (Current)	Coil Resistance	Approval Agency	Relay Type	Operating Temperature [Max]	Operating Temperature [Min]	Must Operate Voltage	Contact Material	Coil Insulation	Coil Current	Mounting Type	Seal Rating	Contact Form
TE Connectivity Potter & Brumfield Relays PCH-124D2H,000	5 ms	10 ms	30 VDC 277 VAC	150 W 1385 VA	Non Latching	PC Pin	24 VDC	1.2 VDC	5 A	1440 Ohms	CQC cURus VDE	General Purpose	85 °C	-40 °C	16.8 VDC	Silver Tin Oxide (AgSnO)	Class F	16.7 mA	Through Hole	Sealed - Fully	SPDT (1 Form C)
TE Connectivity Potter & Brumfield Relays PCH-124D2,000	5 ms	10 ms	30 VDC 277 VAC	150 W 1385 VA	Non Latching	PC Pin	24 VDC	1.2 VDC	5 A	1440 Ohms	CQC cURus VDE	General Purpose	85 °C	-40 °C	16.8 VDC	Silver Tin Oxide (AgSnO)	Class F	16.7 mA	Through Hole	Sealed - Flux Protection	SPDT (1 Form C)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1000	$ 2.05

General part information

General Purpose Relay SPDT (1 Form C) 24VDC Coil Through Hole
