QMS-016-05.75-L-D-DP-A-K

Active

Samtec Inc.

CONN DIFF ARRAY PLG 32P SMD GOLD

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	QMS-016-05.75-L-D-DP-A-K

Connector Type	Differential Pair Array, Male
Contact Finish	Gold
Contact Finish Thickness	10 Áin
Contact Finish Thickness	0.25 Ám
Features	Board Guide, Ground Bus (Plane), Pick and Place
Mounting Type	Surface Mount
Number of Rows	2
Pitch [x]	0.64 mm
Pitch [x]	0.025 in

QMS-016 Series

Part	Pitch [x]	Pitch [x]	Connector Type	Contact Finish	Mounting Type	Height Above Board [z]	Height Above Board [z]	Features	Number of Rows	Contact Finish Thickness	Contact Finish Thickness	Height Above Board	Height Above Board	Mated Stacking Heights	Number of Positions [custom]	Number of Positions [custom]
Samtec Inc. QMS-016-02-SL-D-DP-RA	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Surface Mount Right Angle Through Hole	8.12 mm	0.32 in	Ground Bus (Plane)	2	10 Áin	0.25 Ám
Samtec Inc. QMS-016-01-SL-D-DP-RA-MG	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Surface Mount Right Angle Through Hole	8.12 mm	0.32 in	Ground Bus (Plane) Mating Guide	2	10 Áin	0.25 Ám
Samtec Inc. QMS-016-01-SL-D-DP-RA	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Surface Mount Right Angle Through Hole	8.12 mm	0.32 in	Ground Bus (Plane)	2	10 Áin	0.25 Ám
Samtec Inc. QMS-016-01-L-D-DP-EM2	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Board Edge Straddle Mount			Ground Bus (Plane) Mating Guide	2	10 Áin	0.25 Ám
Samtec Inc. QMS-016-06.75-L-D-DP-PT4	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Surface Mount Through Hole			Board Guide Ground Bus (Plane) Power Pins (8)	2	10 Áin	0.25 Ám	0.25 in	6.35 mm	11 mm 13 mm
Samtec Inc. QMS-016-05.75-L-D-DP-A-GP-K	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Surface Mount			Board Guide Ground Bus (Plane) Mating Guide Pick and Place	2	10 Áin	0.25 Ám	0.212 in	5.38 mm	10 mm 12 mm
Samtec Inc. QMS-016-05.75-L-D-DP-A-K	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Surface Mount			Board Guide Ground Bus (Plane) Pick and Place	2	10 Áin	0.25 Ám
Samtec Inc. QMS-016-06.75-H-D-DP-A	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Surface Mount				2	30 Áin	0.76 Ám	0.25 in	6.35 mm	11 mm 13 mm
Samtec Inc. QMS-016-06.75-H-D-DP-PC4	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Surface Mount Through Hole			Board Guide Ground Bus (Plane) Power Pins (8)	2	30 Áin	0.76 Ám	0.25 in	6.35 mm	11 mm 13 mm	8	32 positions
Samtec Inc. QMS-016-01-L-D-DP-EM2-PC4	0.64 mm	0.025 in	Differential Pair Array Male	Gold	Board Edge Straddle Mount			Ground Bus (Plane) Power Pins (8)	2	10 Áin	0.25 Ám				8	32 positions

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	56	$ 7.63

Description

General part information

QMS-016 Series

32 Position Connector Differential Pair Array, Male Surface Mount Gold

Documents

Technical documentation and resources

No documents available
