KN-1040B

Active

AUTONICS

BAR GRAPH INDICATOR NO ALARM

Search across all available documentation for this part.

Active

AUTONICS

BAR GRAPH INDICATOR NO ALARM

Technical Specifications

Parameters and characteristics for this part

Specification	KN-1040B

Display Type	LED - Red Characters
Measuring Range	Multiple
Measuring Type	Process
Mounting Type	DIN Rail
Number of Characters Per Row	4
Operating Temperature [Max] [custom]	50 °C
Operating Temperature [Min] [custom]	-10 °C
Panel Cutout Dimensions [x]	140.6 mm
Panel Cutout Dimensions [y]	33.6 mm
Termination Style	Screw Terminal
Type	Process Meter
Voltage - Supply [Max]	240 VAC
Voltage - Supply [Min]	100 VAC

BAR GRAPH INDICATOR NO ALARM

Part	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Measuring Range	Voltage - Supply [Min]	Voltage - Supply [Max]	Mounting Type	Operating Temperature [Min] [custom]	Operating Temperature [Max] [custom]	Measuring Type	Type	Display Type	Number of Characters Per Row	Termination Style
AUTONICS KN-1040B	33.6 mm	140.6 mm	Multiple	100 VAC	240 VAC	DIN Rail	-10 °C	50 °C	Process	Process Meter	LED - Red Characters	4	Screw Terminal

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 419.00

General part information

Process Meter LED - Red Characters Display DIN Rail
