PQD6-Q24-S5-D

Obsolete

CUI Inc.

MODULE DC-DC 24VIN 1-OUT 5V 1.2A 6W 4-PIN DIP

Search across all available documentation for this part.

Obsolete

CUI Inc.

MODULE DC-DC 24VIN 1-OUT 5V 1.2A 6W 4-PIN DIP

Technical Specifications

Parameters and characteristics for this part

Part	Approval Agency	Power (Watts)	Type	Voltage - Input (Min) [Min]	Voltage - Isolation	Current - Output (Max) [Max]	Efficiency	Package / Case	Package / Case	Mounting Type	Features	Voltage - Input (Max) [Max]	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Standard Number	Applications	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Number of Outputs
CUI Inc. PQD6-Q24-S5-D	EN	6 W	Isolated Module	9 V	1.5 kV	1.2 A	83 %	4 Lead	5-DIP Module	Through Hole	OCP OVP SCP	36 V	5 V	85 °C	-40 °C	55024	ITE (Commercial)	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	1
CUI Inc. PQD6-Q24-S12-D	EN	6 W	Isolated Module	9 V	1.5 kV	500 mA	87 %	4 Lead	5-DIP Module	Through Hole	OCP OVP SCP	36 V	12 V	85 °C	-40 °C	55024	ITE (Commercial)	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	1
