PLD-02PMFS-QC7001

Active

Amphenol LTW

CERES, OTHERS (PLD), 5A, 02 PINS

Search across all available documentation for this part.

Active

Amphenol LTW

CERES, OTHERS (PLD), 5A, 02 PINS

Technical Specifications

Parameters and characteristics for this part

Specification	PLD-02PMFS-QC7001

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	5 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Number of Positions	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	PL
Shielding	Unshielded
Voltage Rating	250 VDC

Part	Voltage Rating	Orientation	Mounting Feature	Number of Positions	Contact Material	Primary Material	Ingress Protection	Shell Size - Insert	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Shielding	Contact Finish - Mating	Insert Material	Shell Material	Current Rating (Amps)	Color
Amphenol LTW PLD-02PMFS-QC7001	250 VDC	Keyed	Bulkhead - Front Side Nut	2	Copper Alloy	Plastic	IP67 - Dust Tight Waterproof	PL	-40 °C	105 ░C	Receptacle Female Sockets	Unshielded	Gold	Polyamide (PA) Nylon Glass Filled	Glass Filled Nylon Polyamide (PA)	5 A	Black

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 6.29

General part information

2 Position Circular Connector Receptacle, Female Sockets Solder Cup

Technical documentation and resources

No documents available
