DCNLM50NB12
ObsoleteDCNLM 50A 48V NP 12VCOIL/ BULK
DCNLM50NB12
ObsoleteDCNLM 50A 48V NP 12VCOIL/ BULK
Description
General part information
DCNLM50NB12 Series
The DCNLM Series 60V DC Contactor Relay features 50A contact switching capability with a 12V coil rating, which is suitable for a wide variety of applications, including use in electrical control systems, communication power supplies, engineering machines, and uninterruptible power supplies (UPS). This configuration of the DCNLM normally open DC contactor (DCNLM50NB12) features 60V non-polarized main contacts.
Technical Specifications
Parameters and characteristics for this part
| Specification | DCNLM50NB12 |
|---|---|
| Coil Voltage | 12 VAC |
| Contact Form | SPST-NO |
| Contact Rating (Current) | 50 A |
| Form A Count | 1 |
| Mounting Type | Chassis Mount |
| Must Operate Voltage | 8.4 VAC |
| Must Release Voltage | 1 VDC |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -40 °C |
| Switching Voltage DC (Max) | 60 VDC |
| Termination Style | Stud |
