AX4M6M-AU
ActiveMcGill Microwave Systems
CONN XLR CONNECTOR M 4 POS SOLDER CUP ST CABLE MOUNT 4 TERMINAL 1 PORT BOX
AX4M6M-AU
ActiveMcGill Microwave Systems
CONN XLR CONNECTOR M 4 POS SOLDER CUP ST CABLE MOUNT 4 TERMINAL 1 PORT BOX
Description
General part information
AX4M Series
4 Position Circular Connector Receptacle, Male Pins Solder Cup
Technical Specifications
Parameters and characteristics for this part
| Specification | AX4M6M-AU |
|---|---|
| Color | Silver |
| Connector Type | Receptacle, Male Pins |
| Contact Finish - Mating | Gold |
| Current Rating | 10 A |
| Fastening Type | Latch Lock |
| Features | Cable Clamp, Backshell |
| Ingress Protection | IP40 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 4 |
| Operating Temperature (Max) | 75 °C |
| Operating Temperature (Min) | -25 °C |
| Orientation | Keyed |
| Primary Material | Metal |
| Shell Finish | Nickel |
| Shell Material | Zinc Die Cast |
| Shell Size - Insert | XLR |
| Termination | Solder Cup |
