1241.1108.7097

Active

SCHURTER Inc.

SWITCH PUSH SPST-NO 125MA 48V

Search across all available documentation for this part.

Active

SCHURTER Inc.

SWITCH PUSH SPST-NO 125MA 48V

Technical Specifications

Parameters and characteristics for this part

Specification	1241.1108.7097

Actuator Marking	No Marking
Circuit	SPST-NO
Color - Actuator/Cap	Black
Current Rating (Amps)	125 mA
Electrical Life	1000000 Cycles
Features	Tactile Feedback
Ingress Protection	IP65 - Dust Tight, Water Resistant
Mechanical Life	1000000 Cycles
Mounting Type	Through Hole
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-25 °C
Switch Function	Off-Mom
Termination Style	PC Pin
Type	Standard
Voltage Rating - DC	48 V

SWITCH PUSH SPST-NO 125MA 48V

Part	Termination Style	Electrical Life	Voltage Rating - DC	Switch Function	Current Rating (Amps)	Mounting Type	Mechanical Life	Circuit	Ingress Protection	Type	Actuator Marking	Operating Temperature [Min]	Operating Temperature [Max]	Color - Actuator/Cap	Features
SCHURTER Inc. 1241.1108.7097	PC Pin	1000000 Cycles	48 V	Off-Mom	125 mA	Through Hole	1000000 Cycles	SPST-NO	IP65 - Dust Tight, Water Resistant	Standard	No Marking	-25 °C	60 °C	Black	Tactile Feedback

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pushbutton Switch SPST-NO Standard Through Hole
