10121350-101LF

Active

Amphenol ICC (FCI)

CONN HEADER R/A 24POS 2.54MM

Search across all available documentation for this part.

Active

Amphenol ICC (FCI)

CONN HEADER R/A 24POS 2.54MM

Technical Specifications

Parameters and characteristics for this part

Specification	10121350-101LF

Connector Type	Breakaway, Header
Contact Finish - Mating	Gold, GXT™
Contact Finish Thickness - Mating	30 Áin
Contact Finish Thickness - Mating	0.76 Ám
Contact Length - Mating	0.242 in
Contact Length - Mating	6.15 mm
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Male Pin
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole, Right Angle
Number of Positions	24
Number of Positions Loaded	10
Number of Rows	2
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Row Spacing - Mating [x]	2.54 mm
Row Spacing - Mating [x]	0.1 in
Shrouding	Unshrouded
Termination	Solder

Part	Connector Type	Insulation Material	Fastening Type	Insulation Color	Contact Material	Termination	Contact Type	Contact Shape	Material Flammability Rating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions Loaded	Pitch - Mating	Pitch - Mating	Mounting Type	Number of Rows	Shrouding	Number of Positions	Contact Length - Mating	Contact Length - Mating
Amphenol ICC (FCI) 10121350-101LF	Breakaway Header	Thermoplastic	Push-Pull	Black	Phosphor Bronze	Solder	Male Pin	Square	UL94 V-0	2.54 mm	0.1 in	Gold GXT™	30 Áin	0.76 Ám	10	0.1 in	2.54 mm	Through Hole Right Angle	2	Unshrouded	24	0.242 in	6.15 mm
