M48Z512A-70PM1
ObsoleteSTMicroelectronics
IC NVSRAM 4MBIT PARALLEL 32PMDIP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
M48Z512A-70PM1
ObsoleteSTMicroelectronics
IC NVSRAM 4MBIT PARALLEL 32PMDIP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | M48Z512A-70PM1 |
|---|---|
| Access Time | 70 ns |
| Memory Format | NVSRAM |
| Memory Interface | Parallel |
| Memory Organization | 512 K |
| Memory Size | 512 kb |
| Memory Type | Non-Volatile |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | 0 °C |
| Package / Case | 0.6 in |
| Package / Case | 15.24 mm |
| Package / Case | 32-DIP Module |
| Supplier Device Package | 32-PMDIP Module |
| Technology | NVSRAM (Non-Volatile SRAM) |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 4.75 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
M48Z512 Series
NVSRAM (Non-Volatile SRAM) Memory IC 4Mbit Parallel 70 ns 32-PMDIP Module
