TR15G200MFNES
ActiveVishay Dale
THICK FILM RESISTORS - THROUGH HOLE 1.5W 200MOHMS 1% 200PPM
TR15G200MFNES
ActiveVishay Dale
THICK FILM RESISTORS - THROUGH HOLE 1.5W 200MOHMS 1% 200PPM
Description
General part information
TR Series
200 MOhms ±1% 1.5W Through Hole Resistor Radial High Voltage Thick Film
Technical Specifications
Parameters and characteristics for this part
| Specification | TR15G200MFNES |
|---|---|
| Composition | Thick Film |
| Features | High Voltage |
| Height - Seated (Max) | 0.385 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Package Name | Radial |
| Power (Watts) | 1.5 W |
| Resistance | 200 MOhm |
| Size / Dimension Length | 1.5 in |
| Size / Dimension Width | 0.125 in |
| Temperature Coefficient | 200 ppm/°C |
| Tolerance | 1 % |
