W3AF1C-P12MFG0-7500

Active

ODU

ODU MINI-SNAP RT.ANGLE PLUG, STY

Search across all available documentation for this part.

Active

ODU

ODU MINI-SNAP RT.ANGLE PLUG, STY

Technical Specifications

Parameters and characteristics for this part

Specification	W3AF1C-P12MFG0-7500

Applications	Military, Medical, Industrial, Testing Equipment & Measurement
Backshell Material, Plating	Brass, Chrome over Nickel
Cable Opening [custom]	0.295 in, 0.276 in
Cable Opening [custom]	7 mm
Cable Opening [custom]	7.5 mm
Color	Silver
Connector Type	Plug, Male Pins
Contact Finish - Mating	Gold
Contact Material	Brass
Current Rating (Amps)	7.5 A
Fastening Type	Push-Pull
Features	Backshell
Ingress Protection	IP68 - Dust Tight, Waterproof
Insert Material	Polyetheretherketone (PEEK)
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line), Right Angle
Number of Positions	12
Operating Temperature [Max]	120 °C
Operating Temperature [Min]	-40 °C
Orientation	1
Primary Material	Metal
Shell Finish	Chrome over Nickel
Shell Material	Brass
Shell Size - Insert	1.5
Shielding	Unshielded
Voltage Rating	300 VDC

ODU MINI-SNAP RT.ANGLE PLUG, STY

Part	Contact Finish - Mating	Backshell Material, Plating	Orientation	Connector Type	Primary Material	Insert Material	Ingress Protection	Current Rating (Amps)	Number of Positions	Material Flammability Rating	Fastening Type	Shell Finish	Color	Voltage Rating	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Shell Material	Shielding	Contact Material	Applications	Cable Opening [custom]	Cable Opening [custom]	Cable Opening [custom]	Shell Size - Insert	Features
ODU W3AF1C-P12MFG0-7500	Gold	Brass, Chrome over Nickel	1	Male Pins, Plug	Metal	Polyetheretherketone (PEEK)	IP68 - Dust Tight, Waterproof	7.5 A	12	UL94 V-0	Push-Pull	Chrome over Nickel	Silver	300 VDC	Free Hanging (In-Line), Right Angle	-40 °C	120 °C	Brass	Unshielded	Brass	Industrial, Medical, Military, Testing Equipment & Measurement	0.276 in, 0.295 in	7 mm	7.5 mm	1.5	Backshell

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 160.59

General part information

12 Position Circular Connector Plug, Male Pins Solder Cup
