MCC750-1T48-PC

Active

Bel Power Solutions

AC/DC POWER SUPPLY SINGLE-OUT 48V 15.6A 750W 23-PIN

Search across all available documentation for this part.

Active

Bel Power Solutions

AC/DC POWER SUPPLY SINGLE-OUT 48V 15.6A 750W 23-PIN

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	MCC750-1T48-PC	MCC750 Series

Applications	Medical	Medical
Approval Agency	cURus, DEMKO, CE	cURus, DEMKO, CE
Current - Output 1	15.6 A	15.6 - 31.5 A
Efficiency	94 %	94 %
Features	Universal Input, Remote Sense, Remote On/Off, Adjustable Output, PFC	Universal Input, Remote Sense, Remote On/Off, Adjustable Output, PFC
Minimum Load Required	False	False
Mounting Type	Chassis Mount	Chassis Mount
Number of Outputs	1	1
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	-20 °C	-20 °C
Power (Watts)	749 W	749 - 756 W
Size / Dimension [x]	234.8 mm	234 - 234.8 mm
Size / Dimension [x]	9.24 in	9.21 - 9.24 in
Size / Dimension [y]	101.6 mm	101.6 mm
Size / Dimension [y]	4 "	4 "
Size / Dimension [z]	41 mm	41 mm
Size / Dimension [z]	1.61 "	1.61 "
Standard Number	60601-1	60601-1
Type	Enclosed	Enclosed, Open Frame
Voltage - Input [Max]	305 VAC, 300 VDC	300 - 305 VAC
Voltage - Input [Min]	120 VDC, 85 VAC	85 - 120 VDC
Voltage - Isolation	4000 V	4000 V
Voltage - Output 1	48 V	24 - 48 V

AC/DC POWER SUPPLY SINGLE-OUT 48V 15.6A 750W 23-PIN

Part	Voltage - Isolation	Standard Number	Power (Watts)	Mounting Type	Approval Agency	Voltage - Input [Max]	Voltage - Input [Min]	Features	Voltage - Output 1	Current - Output 1	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Type	Efficiency	Number of Outputs	Operating Temperature [Min]	Operating Temperature [Max]	Applications
Bel Power Solutions MCC750-1T48-PC	4000 V	60601-1	749 W	Chassis Mount	CE, cURus, DEMKO	300 VDC, 305 VAC	85 VAC, 120 VDC	Adjustable Output, PFC, Remote On/Off, Remote Sense, Universal Input	48 V	15.6 A	234.8 mm	41 mm	1.61 "	9.24 in	101.6 mm	4 "	Enclosed	94 %	1	-20 °C	70 °C	Medical
Bel Power Solutions MCC750-1T24-PC	4000 V	60601-1	756 W	Chassis Mount	CE, cURus, DEMKO	300 VDC, 305 VAC	85 VAC, 120 VDC	Adjustable Output, PFC, Remote On/Off, Remote Sense, Universal Input	24 V	31.5 A	234.8 mm	41 mm	1.61 "	9.24 in	101.6 mm	4 "	Enclosed	94 %	1	-20 °C	70 °C	Medical
Bel Power Solutions MCC750-1T24	4000 V	60601-1	756 W	Chassis Mount	CE, cURus, DEMKO	300 VDC, 305 VAC	85 VAC, 120 VDC	Adjustable Output, PFC, Remote On/Off, Remote Sense, Universal Input	24 V	31.5 A	234 mm	41 mm	1.61 "	9.21 in	101.6 mm	4 "	Open Frame	94 %	1	-20 °C	70 °C	Medical

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Arrow	N/A	1	$ 696.00
		2	$ 683.57
Digikey	Box	20	$ 686.85
Newark	Each	1	$ 721.47

General part information

Enclosed AC DC Converters 1 Output 48V 85 ~ 305 VAC, 120 ~ 300 VDC Input
