Specification	3-641213-5

Applications	General Purpose
Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	30 µin
Contact Finish Thickness - Post	150 µin
Contact Length - Mating	0.295 in
Contact Length - Post	0.14 in
Contact Material	Copper Alloy
Contact Shape	Square
Contact Type	Male Pin
Current Rating	0 A
Current Rating	Varies by Wire Gauge
Insulation Color	Natural
Insulation Height	0.305 in
Insulation Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	5
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-55 °C
Overall Contact Length	0.535 in
Pitch - Mating	0.1 in
Shrouding	Shrouded - 1 Wall
Style	Cable/Wire, Board
Termination	Solder
Voltage Rating	250 V

641213 Series

Part	Contact Finish - Post	Contact Length - Post	Insulation Height	Connector Type	Overall Contact Length	Current Rating	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Material	Number of Positions	Insulation Color	Number of Positions Loaded	Number of Rows	Mounting Type	Operating Temperature (Min)	Operating Temperature (Max)	Contact Shape	Contact Type	Voltage Rating	Material Flammability Rating	Contact Length - Mating	Shrouding	Termination	Pitch - Mating	Insulation Material	Style	Contact Finish Thickness - Post	Applications
TE Connectivity AMP Connectors 5-641213-8	Tin	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	28	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
TE Connectivity AMP Connectors 3-641213-6	Tin	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	6	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
TE Connectivity AMP Connectors 641213-8	Tin-Lead	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	8	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
TE Connectivity AMP Connectors 641213-7	Tin-Lead	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	7	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
TE Connectivity AMP Connectors 4-641213-5	Tin	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	15	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
TE Connectivity AMP Connectors 3-641213-9	Tin	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	9	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
TE Connectivity AMP Connectors 641213-2	Tin-Lead	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	2	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
TE Connectivity AMP Connectors 3-641213-7	Tin	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	7	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
TE Connectivity AMP Connectors 641213-4	Tin-Lead	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	4	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
TE Connectivity AMP Connectors 3-641213-5	Tin	0.14 in	0.305 in	Header	0.535 in	Varies by Wire Gauge	Gold	30 µin	Copper Alloy	5	Natural	All	1	Through Hole	-55 °C	105 °C	Square	Male Pin	250 V	UL94 V-0	0.295 in	Shrouded - 1 Wall	Solder	0.1 in	Thermoplastic	Board Cable/Wire	150 µin	General Purpose
