MX581TH
ActiveAnalog Devices Inc./Maxim Integrated
MX581 10V REFERENCE
Deep-Dive with AI
Search across all available documentation for this part.
MX581TH
ActiveAnalog Devices Inc./Maxim Integrated
MX581 10V REFERENCE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MX581TH |
|---|---|
| Current - Output | 10 mA |
| Current - Supply | 1 mA |
| Mounting Type | Through Hole |
| Noise - 0.1Hz to 10Hz | 50 µVp-p |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Output Type | 1.81 mOhm |
| Package / Case | TO-39-3 Metal Can, TO-205AD |
| Reference Type | Series |
| Supplier Device Package | TO-39 |
| Temperature Coefficient | 15 ppm/°C |
| Tolerance | 1 % |
| Voltage - Input [Max] | 30 V |
| Voltage - Input [Min] | 12.5 V |
| Voltage - Output (Min/Fixed) | 10 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 16 | $ 19.85 | |
MX581 Series
MX581 10V REFERENCE
| Part | Current - Output | Supplier Device Package | Temperature Coefficient | Current - Supply | Output Type | Mounting Type | Voltage - Input [Min] | Voltage - Input [Max] | Voltage - Output (Min/Fixed) | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Tolerance | Noise - 0.1Hz to 10Hz | Reference Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MX581TH | 10 mA | TO-39 | 15 ppm/°C | 1 mA | 1.81 mOhm | Through Hole | 12.5 V | 30 V | 10 V | -55 °C | 125 °C | TO-205AD, TO-39-3 Metal Can | 1 % | 50 µVp-p | Series |
Description
General part information
MX581 Series
Series Voltage Reference IC Fixed 10V V ±1% 10 mA TO-39
Documents
Technical documentation and resources
No documents available
