LX1993CDU-T
ObsoleteMicrosemi Corporation
IC LED DRV RGLTR PWM 300MA 8MSOP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
LX1993CDU-T
ObsoleteMicrosemi Corporation
IC LED DRV RGLTR PWM 300MA 8MSOP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | LX1993CDU-T |
|---|---|
| Applications | Backlight |
| Current - Output / Channel | 300 mA |
| Dimming | Analog, PWM |
| Internal Switch(s) | True |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | 0 °C |
| Package / Case | 8-MSOP, 8-TSSOP |
| Package / Case | 3 mm |
| Package / Case [custom] | 0.118 in |
| Supplier Device Package | 8-MSOP |
| Topology | Step-Up (Boost) |
| Type | DC DC Regulator |
| Voltage - Supply (Max) [Max] | 6 V |
| Voltage - Supply (Min) [Min] | 1.6 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
LX1993 Series
LED Driver IC 1 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 300mA (Switch) 8-MSOP
