BC188

Active

Sierra Wireless

RF TXRX MOD WIFI TH SMD

Search across all available documentation for this part.

Active

Sierra Wireless

RF TXRX MOD WIFI TH SMD

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	BC188	BC188 Series

Antenna Type	Integrated, Trace	Integrated, Trace
Data Rate	72.2 Mbps	72.2 Mbps
For Use With/Related Products	-	BC188
Frequency	2.4 GHz	2.4 GHz
Mounting Type	Surface Mount	Surface Mount
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Package / Case	62-SMD Module	62-SMD Module
Power - Output	26 dBm	26 dBm
Protocol	802.11b/g/n	802.11b/g/n
RF Family/Standard	WiFi	WiFi
Sensitivity	-15 dBm	-15 dBm
Serial Interfaces	SPI, I2C, I2S, UART	SPI, I2C, I2S, UART
Supplied Contents	-	Board(s)
Type	-	Transceiver; 802.11 b/g/n (Wi-Fi, WiFi, WLAN)
Utilized IC / Part	BC188	BC188
Voltage - Supply [Max]	3.6 V	3.6 V
Voltage - Supply [Min]	3 V	3 V

DISCOVERY KIT BC188

Part	Frequency	For Use With/Related Products	Supplied Contents	Type	Package / Case	Antenna Type	Utilized IC / Part	Voltage - Supply [Max]	Voltage - Supply [Min]	RF Family/Standard	Power - Output	Mounting Type	Protocol	Data Rate	Serial Interfaces	Operating Temperature [Max]	Operating Temperature [Min]	Sensitivity
Sierra Wireless BC188-DISKIT001	2.4 GHz	BC188	Board(s)	Transceiver; 802.11 b/g/n (Wi-Fi, WiFi, WLAN)
Sierra Wireless BC188	2.4 GHz				62-SMD Module	Integrated, Trace	BC188	3.6 V	3 V	WiFi	26 dBm	Surface Mount	802.11b/g/n	72.2 Mbps	I2C, I2S, SPI, UART	85 °C	-40 °C	-15 dBm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	1000	$ 16.37

General part information

WiFi 802.11b/g/n Transceiver Module 2.4GHz Integrated, Trace Surface Mount
