General part information
8 (4 Pair) Conductor Multi-Pair, Cat6a Cable Red 23 AWG 1000.0' (304.8m)
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 10GXS12002A1000 | 10GXS12 Series |
|---|---|---|
| Cable Type | Multi-Pair, Cat6a | Multi-Pair, Cat6a |
| Conductor Insulation | Polyolefin (PO) | Polyolefin (PO) |
| Conductor Material | Copper, Bare | Copper, Bare |
| Conductor Strand | Solid | Solid |
| Features | Rip Cord | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 6.99 mm | 6.99 mm |
| Jacket (Insulation) Diameter [diameter] | 0.275 in | 0.275 in |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | Red | Green, Gray, Yellow, Purple, Orange, Red, Blue |
| Length | 1000 ft | 1000 ft |
| Length | 304.8 m | 304.8 m |
| Number of Conductors | 8 | 8 |
| Ratings | UL Style CMR | UL Style CMR |
| Usage | Network | Network |
| Voltage | 300 V | 300 V |
| Wire Gauge | 23 AWG | 23 AWG |
CAT6A 4PR U/UTP CMR REEL
| Part | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Number of Conductors | Jacket (Insulation) Material | Cable Type | Conductor Material | Usage | Jacket Color | Features | Wire Gauge | Conductor Insulation | Voltage | Conductor Strand | Length | Length | Ratings |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 10GXS12 0051000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Green | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
Belden Inc. 10GXS12008A1000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Gray | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
Belden Inc. 10GXS12004A1000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Yellow | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
Belden Inc. 10GXS12 0071000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Purple | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
Belden Inc. 10GXS12 0081000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Gray | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
Belden Inc. 10GXS12003A1000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Orange | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
Belden Inc. 10GXS12 0041000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Yellow | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
Belden Inc. 10GXS12002A1000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Red | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
Belden Inc. 10GXS12006A1000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Blue | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
Belden Inc. 10GXS12 0061000 | 6.99 mm | 0.275 in | 8 | Poly-Vinyl Chloride (PVC), Riser | Multi-Pair, Cat6a | Copper, Bare | Network | Blue | Rip Cord | 23 AWG | Polyolefin (PO) | 300 V | Solid | 1000 ft | 304.8 m | UL Style CMR |
